Richelieu WEBKIT1220225 Grant TopLine Low Profile Sliding Door SystemRichelieu WEBKIT1220225 Grant TopLine Low Profile Straight Sliding Door System offers a stylish and functional solution for both commercial and residential applications. Designed to accommodate low profile wood doors weighing up to 500 lb (227 kg) and at least 1 3/8 in (35 mm) thick, this system excels in environments with limited headroom, making it ideal for closets and walk-in spaces. The sliding door system features precision ball bearing wheel trolleys that glide effortlessly along durable aluminum box tracks, ensuring smooth and silent operation. For added convenience, a separate Silent System soft-close and soft-open mechanism is available for doors weighing up to 325 lb (147 kg), enhancing the user experience with a touch of luxury. This versatile system supports single sliding, biparting, and bypassing door configurations, providing flexibility to meet various design needs. The maximum door height is 9 ft 10 in, with widths ranging from 30 to 94 1/2 in. Each installation requires a properly framed opening, and it is crucial to follow the manufacturer's instructions for the best results. Ensure to pre-drill all screws and keep tracks clean during installation. With the Richelieu Grant TopLine, elevate your space with a blend of elegance and functionality.
Grant TopLine Low Profile Straight Sliding Door System
The Grant TopLine Low Profile Straight Sliding Door System, featuring the Grant TopLine SD, Grant TopLine HD and Grant TopLine XHD, is made for low profile wood doors weighing up to 500 lb (227 kg) each and at least 1 3/8 in (35 mm) thick.
- Sleek and elegant look
- Precision ball bearing wheel trolleys run on aluminum box tracks
- Silent System soft-close and soft-open mechanism available separately for doors weighing up to 325 lb (147 kg) each.
These models are designed for commercial and residential use with single, biparting, and bypassing door applications and are ideal for restricted headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Cabinet, Storage
Brand: Grant Hettich
Detailed Door Movement: Single Sliding
Door Height: Max. 3 000 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 35 to 45 mm
Door Width: 762 to 2 400 mm
Grant Top Line Model: Grant TopLine SD
Length - Overall Dimensions: 12 ft*
Load Capacity: Max. 150 lb*
Number of Doors: 1
Overall Length: 3 658 mm
Product #: WEBKIT1220225
Product number: WEBKIT1220225
Product №: WEBKIT1220225
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
Track Length: 3 658 mm
Track Mounting: Wall Mount
Weight Capacity per Door: Max. 68 kg
