Richelieu WEBKIT1242698 APEX Recessed Profile Interior Cabinet Starter GuideRichelieu WEBKIT1242698 APEX RECESSED PROFILE Interior Cabinet - Starter Guide offers an elegant lighting solution designed for seamless integration into your cabinetry. The Apex profile is available in two convenient lengths-78 3/4" (2 m) and 118 1/8" (3 m)-and can be easily trimmed with a miter saw to meet your specific dimensions. The profile measures 3/8" (9 mm) in width and 7/16" (10.5 mm) in height, ensuring a sleek fit. Equipped with the FlexyLED HE6 PW LED strip, this system boasts an impressive density of 280 LEDs per meter, delivering efficient performance at 9.6 watts per meter. The LED strip is available in several fixed lengths, allowing for flexibility in installation. A pre-wired 78" power cable simplifies setup, while extension cables in 20", 40", and 78" lengths offer further customization. The IR-XD3 control system is recessed for a flush finish, and the recommended distance from the light to the power supply is 24 feet. With a color rendering index (CRI) of 80 and a neutral white light at 4200 K, this lighting solution is perfect for kitchens, living rooms, bedrooms, offices, and closets. Compliant with UL, CE, and cULus standards, the Richelieu APEX system is an ideal choice for both professionals and discerning homeowners.
APEX RECESSED PROFILE Interior Cabinet - Starter Guide
Control type:
- X-Driver IR-XD3 Wired Sensor
The benefits of this set are:
- Apex profile, available in two lengths: 78 3/4" (2 m) and 118 1/8" (3 m), can be cut easily with a miter saw.
- Apex profile dimensions: 3/8" (9 mm) W x 7/16" (10.5 mm) H.
- FlexyLED HE6 PW is a LED strip with 280 LED/meter on a circuit 1/4" (6 mm) wide; 9.6 watts/meter.
- FlexyLED HE6 PW available in fixed lengths (trimmable): 19 11/16" (500 mm), 39 3/8" (1000 mm), 59 1/16" (1500 mm), 78 3/4" (2000 mm), 98 7/16" (3000 mm).
- 78" power cable is pre-wired to the FlexyLED HE6 PW.
- Extension cables are available in 20", 40" and 78".
- IR-XD3 is recessed in a 13/32" (10 mm) hole, flush to the door.
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen, Living Room, Bedroom, Office, Furniture, Closet
CRI ( Color Rendering Index): 80
Compatibility: Micro 24
Control System: IR
Features: Bluetooth, Wi-Fi
Group: LED Group A
IP: IP20
Kelvin Color Temperature ( K): 4200 K
Light Color: Neutral White
Lighting: Task
Lighting Type: LED
Location: Inside Cabinet
Luminaire: Flexible Linear
Luminous Efficiency: 82 lm/W
Mounting: Recessed
Operation: Wi-Fi
Product #: WEBKIT1242698
Product №: WEBKIT1242698
Standards and Certifications: UL, CE, cULus
Watts: 9.6 W
