Richelieu WEBKIT1242917 FLEXYLED SEH4 Corner Cabinet Starter GuideRichelieu WEBKIT1242917 FLEXYLED SEH4 Corner Cabinet - Starter Guide offers an innovative lighting solution tailored for modern cabinetry. This flexible LED strip is designed to enhance functionality and aesthetics in your kitchen or workspace. With a variety of fixed lengths available-from 39 3/8" (1000 mm) to 118 1/8" (3000 mm)-this product can be easily trimmed to fit your specific needs. Equipped with a silicone coating, the LED strip features 180 LEDs per meter, delivering a luminous efficiency of 75 lm/W at a neutral white color temperature of 4200 K. The IR WI-XD wireless sensor ensures seamless control, providing proximity operation within a 24-foot range. Installation is straightforward, with a pre-wired 78" power cable, enabling convenient setup for a 34 1/2" height base cabinet. Designed for recessed mounting in a groove measuring 4 mm wide x 8 mm deep, this product adheres to local electrical codes and carries certifications from UL and CE for safety. The FLEXYLED SEH4 not only enhances the functional lighting of your cabinets but also contributes to a sophisticated ambiance. Elevate your cabinetry with Richelieu's cutting-edge lighting solutions, combining convenience with modern design.
FLEXYLED SEH4 Corner Cabinet - Starter Guide
Control type:
- X-Driver IR WI-XD Wireless Sensor
The benefits of this set are:
- Available in fixed lengths (trimmable): 39 3/8" (1000 mm), 59 1/16" (1500 mm), 78 3/4" (2000 mm), 98 7/16" (2500 mm), 118 1/8" (3000 mm).
- Silicone coated LED with 180 LED/meter; 9.6 watts/meter.
- Recess into a groove measuring 4 mm wide x 8 mm deep.
- Kits recommended for a 34 1/2" height base cabinet.
- 78" power cable is pre-wired at each end of the roll. Cut off unused wire at designated marks.
- IR WI-XD is a self-powered wireless proximity sensor (with lithium battery CR2450).
- Recommended to only go a distance of 24-ft from the light to the power supply.
- Run low voltage wiring between the LED and power supply (supplied by others). Terminal connectors are included.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Important information
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
CRI ( Color Rendering Index): 90
Compatibility: Micro 24
Connection Type: Micro 24
Control System: IR
Features: Bluetooth, Wi-Fi
Group: LED Group A
IP: IP44
Kelvin Color Temperature ( K): 4200 K
LED Strip Length: 78 3/4 in*
Length of second power cable: 78 3/4 in*
Light Color: Neutral White
Lighting: Functional
Lighting Type: LED
Location: Inside Cabinet
Luminaire: Flexible Linear
Luminous Efficiency: 75 lm/W
Material: Silicone
Mounting: Recessed
Operation: Proximity
Power Cable: Double
Product #: WEBKIT1242917
Recessed Depth: 13/32 in*
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standards and Certifications: UL, CE
Tension ( V): 24 V
Watts/ Foot: 2.92 W
Width: 5/32 in*
