Richelieu WEBKIT1242959 CINETTO PS40.2 Coplanar Sliding SystemRichelieu WEBKIT1242959 CINETTO PS40.2 Coplanar Sliding System is designed for seamless and stylish access to large cabinet doors, supporting weights of up to 132 lb (60 kg) each. This innovative sliding system accommodates one, two, or even three wood doors, making it a versatile choice for various applications, including closets, pantries, and wardrobes in both residential and commercial settings. The Cinetto PS40.2 features adjustable surface mount hardware for easy installation, along with a soft-close mechanism that ensures quiet and controlled door movement. Notably, no special cabinet fabrication is required, simplifying the setup process. It is available in two attractive track finishes: silver and stainless steel effect anodized aluminum, allowing you to choose the perfect match for your space. Designed to fit doors with a thickness ranging from 3/4 to 1 9/16 inches and widths between 35 to 48 1/4 inches, this system offers flexibility in design. For optimal performance, it is recommended to use a door straightener/stiffener to enhance rigidity. With a height clearance of 5 5/32 inches and an overall length of 11 ft 9 in, the Cinetto PS40.2 is a robust solution for any upscale cabinetry project.
CINETTO PS40.2 Coplanar Sliding System
Cinetto PS40.2 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
- Flexible system for one, two, or three wood doors
- Surface mount hardware, adjustable
- Soft-close mechanism included
- No special cabinet fabrication is required
- Two types of track finishes: silver and stainless steel effect anodized aluminum
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to make the door more rigid.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Detailed Door Movement: Bypassing
Door Height: 3 000 mm
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 16 to 55 mm
Door Width: 888 to 1 225 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length - Overall Dimensions: 11 ft 9 in*
Load Capacity: 99.2 to 220 lb*
Manufacturing Material: Aluminum
Number of Doors: 2
Opening: Towards the right / Towards the left
Overall Length: 3 600 mm
PS40 Opening: Towards the left / Towards the right
Product #: WEBKIT1242959
Product number: WEBKIT1242959
Product №: WEBKIT1242959
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Material: Anodized Aluminum
Weight Capacity per Door: 45 to 100 kg
