Richelieu WEBKIT1243031 ATOM Under Cabinet LED Puck Light - Starter GuideRichelieu WEBKIT1243031 ATOM puck LED for Under Cabinet Lighting offers a versatile and efficient lighting solution ideal for kitchens, living rooms, and commercial spaces. This stylish fixture features a warm white light with a color temperature of 3000 K and a high Color Rendering Index (CRI) of 90, ensuring your spaces are illuminated beautifully and accurately. Designed for ease of use, the ATOM light can be controlled via a Wi-Fi app, a touch dimmer, or a Bluetooth wall dimmer, giving you multiple options for convenient operation. It is recommended for use over a 48-inch counter, and for longer installations, additional puck lights can be added every 15 inches. The fixture supports both recessed and surface mounting, with a trim ring available separately. With a fixed spot luminaire that emits 180 lumens at an efficiency of 60 lm/W, the ATOM light is powered by a pre-wired 78-inch power cable, while extension cables are available in various lengths. Please note, installation must comply with local electrical codes, and it is advisable to consult with a qualified electrician. The ATOM combines contemporary design with practical functionality, making it a perfect choice for modern living spaces.
ATOM puck LED for Under Cabinet Lighting - Started Guide
Select your control type:
- Wi-Fi App.
- Touch Me Dimmer
- Decora Bluetooth Wall Dimmer
(Power supply features optional plug-in installation with detachable power cable.)
- Switchex® Wall Dimmer/Driver
(Switchex® mounts in a standard in-wall switch box, accepts 120 Vac and converts to low voltage dc.)
The benefits of this set are:
- Kits recommended for a 48" counter.
- For longer counters, add a puck light every 15" CTC.
- The Atom can be recessed or surface mounted using the trim ring (sold separately).
- 78" power cable is pre-wired to the Atom.
- Extension cables are available in 20", 40" and 78".
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen, Living Room, Commercial, Furniture
Bore Hole: 2 1/4 in*
CRI ( Color Rendering Index): 90
Compatibility: Micro 24
Connection Type: Micro 24
Control System: Dimmer
Diameter: 2 11/16 in*
Finish: Black
Group: LED Group A, LED 24 V dc Exclusive
Height: 11/32 in*
IP: IP20
Kelvin Color Temperature ( K): 3000 K
Light Color: Warm White
Lighting: Accent, Task
Lighting Type: LED
Location: Under Cabinet
Luminaire: Fixed Spots
Luminous Efficiency: 60 lm/W
Luminous Flux: 180 Lumen
Mounting: Recessed
Operation: Touch / Wall
Product #: WEBKIT1243031
Product №: WEBKIT1243031
Recessed Depth: 5/16 in*
Standards and Certifications: UL, ETL, ULC, CE, cULus
Style: Contemporary
Tension ( V): 24 V
Watts: 3 W
