Richelieu WEBKIT1245763 BLADE Under Cabinet Surface Profile Starter GuideRichelieu WEBKIT1245763 BLADE SURFACE PROFILE Under Cabinet - Starter Guide offers an innovative solution for enhancing your lighting experience in kitchens, living rooms, and commercial spaces. This starter guide features a sleek blade profile measuring 78 3/4" (2 m) in length, which can be easily cut with a miter saw to fit your specific needs. The dimensions of the blade profile are 13/16" (21 mm) W x 3/8" (10 mm) H, allowing it to seamlessly integrate into any contemporary design. The FlexyLED UHE6B PW LED strip included in the kit boasts an impressive density of 280 LEDs/m on a 1/4" (6 mm) wide circuit, delivering exceptional task and accent lighting with a warm color temperature of 3000 K. This versatile kit is recommended for 96" counters and is pre-wired with a 78" power cable to ensure straightforward installation. Multiple control options are available, including Bluetooth dimmers, wall dimmers, and a Wi-Fi driver, providing flexibility in operation. Additionally, extension cables are offered in various lengths for customized setups, while compliance with local electrical codes is essential during installation. With its modern aesthetic and smart technology capabilities, the Richelieu BLADE SURFACE PROFILE is designed to elevate your lighting solutions effortlessly.
BLADE SURFACE PROFILE Under Cabinet - Starter Guide
Select your control type:
- X-Driver Wi-Fi
- Touch Me Dimmer
- Decora Bluetooth Wall Dimmer
(Power supply features optional plug-in installation with detachable power cable.)
- Switchex® LED Dimmer/Power Supply
(Switchex® mounts in a standard in-wall switch box, accepts 120 Vac and converts to low voltage dc.)
The benefits of this set are:
- Blade profile, 78 3/4" (2 m) L, easily cut with a miter saw.
- Blade profile dimensions: 13/16" (21 mm) W x 3/8" (10 mm) H.
- FlexyLED UHE6B PW is a LED strip with 280 LED/m on a circuit 1/4" (6 mm) W.
- FlexyLED UHE6B PW available in fixed lengths (trimmable): 19 11/16" (500 mm), 39 3/8" (1000 mm), 59 1/16" (1500 mm), 78 3/4" (2000 mm).
- Kits recommended for a 96" counter.
- 78" power cable is pre-wired to the FlexyLED UHE6B PW.
- Extension cables are available in 20", 40" and 78".
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen, Living Room, Commercial, Furniture
Compatibility: Micro 24
Control System: Bluetooth / Dimmer
Finish: Black
Group: LED Group A, LED 24 V dc Exclusive
Kelvin Color Temperature ( K): 3000 K
Lighting: Accent, Task
Lighting Type: LED
Location: Under Cabinet
Luminaire: Rigid Linear
Mounting: Recessed
Operation: Smart Technology (Bluetooth) / Wall
Product #: WEBKIT1245763
Product №: WEBKIT1245763
Style: Contemporary
Tension ( V): 24 V
Watts: 5 W
