Richelieu WEBKIT1245765 BLADE Surface Profile Under Cabinet Starter GuideRichelieu WEBKIT1245765 BLADE SURFACE PROFILE Under Cabinet Starter Guide offers an innovative lighting solution designed for modern kitchens and living spaces. This versatile system allows you to select your preferred control type, including X-Driver Wi-Fi, Touch Me Dimmer, Decora Bluetooth Wall Dimmer, or the Switchex® LED Dimmer/Power Supply, accommodating a variety of installation preferences. The blade profile measures an impressive 78 3/4" (2 m) in length, and can be easily cut with a miter saw to fit your specific needs. With dimensions of 13/16" (21 mm) W x 3/8" (10 mm) H, it seamlessly integrates into your cabinetry for a sleek appearance. The FlexyLED UHE6B PW LED strip features 280 LEDs per meter on a 1/4" (6 mm) wide circuit, available in various trimmable lengths to suit your project. This system is optimized for accent and task lighting, operating at a color temperature of 4000 K. Pre-wired with a 78" power cable and compatible with micro 24, it supports a recommended distance of up to 24 feet from the light to the power supply. Ideal for both residential and commercial applications, the Richelieu BLADE SURFACE PROFILE enhances functionality while elevating the aesthetic of any space.
BLADE SURFACE PROFILE Under Cabinet - Starter Guide
Select your control type:
- X-Driver Wi-Fi
- Touch Me Dimmer
- Decora Bluetooth Wall Dimmer
(Power supply features optional plug-in installation with detachable power cable.)
- Switchex® LED Dimmer/Power Supply
(Switchex® mounts in a standard in-wall switch box, accepts 120 Vac and converts to low voltage dc.)
The benefits of this set are:
- Blade profile, 78 3/4" (2 m) L, easily cut with a miter saw.
- Blade profile dimensions: 13/16" (21 mm) W x 3/8" (10 mm) H.
- FlexyLED UHE6B PW is a LED strip with 280 LED/m on a circuit 1/4" (6 mm) W.
- FlexyLED UHE6B PW available in fixed lengths (trimmable): 19 11/16" (500 mm), 39 3/8" (1000 mm), 59 1/16" (1500 mm), 78 3/4" (2000 mm).
- Kits recommended for a 96" counter.
- 78" power cable is pre-wired to the FlexyLED UHE6B PW.
- Extension cables are available in 20", 40" and 78".
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen, Living Room, Commercial, Furniture
Compatibility: Micro 24
Control System: Wi-Fi
Finish: Aluminum
Group: LED Group A, LED 24 V dc Exclusive
Kelvin Color Temperature ( K): 4000 K
Lighting: Accent, Task
Lighting Type: LED
Location: Under Cabinet
Luminaire: Rigid Linear
Mounting: Recessed
Operation: Wi-Fi
Product #: WEBKIT1245765
Product №: WEBKIT1245765
Style: Contemporary
Tension ( V): 24 V
Watts: 5 W
