Richelieu WEBKIT1245769 BLADE Under Cabinet Surface Profile Starter GuideRichelieu WEBKIT1245769 BLADE SURFACE PROFILE Under Cabinet - Starter Guide offers a sleek and modern solution for enhancing your space with effective lighting. This versatile kit features a blade profile measuring 78 3/4" (2 m) in length, which can be easily cut to fit your specific needs using a miter saw. The dimensions of the blade profile are 13/16" (21 mm) in width and 3/8" (10 mm) in height, making it a perfect addition to various applications, including kitchens, living rooms, and commercial settings. Equipped with FlexyLED UHE6B PW LED strips, this system boasts an impressive density of 280 LEDs per meter, ensuring ample illumination for accent and task lighting. The lighting comes in fixed lengths that are trimmable, with options ranging from 19 11/16" (500 mm) to 78 3/4" (2000 mm). For seamless integration, the power cable is pre-wired to the LED strip, and extension cables are available in various lengths. The kit is compatible with multiple control systems, including Bluetooth and dimmers, allowing for easy operation. With a contemporary aluminum finish and a color temperature of 4000 K, this under-cabinet lighting solution combines functionality with style, perfect for any modern space.
BLADE SURFACE PROFILE Under Cabinet - Starter Guide
Select your control type:
- X-Driver Wi-Fi
- Touch Me Dimmer
- Decora Bluetooth Wall Dimmer
(Power supply features optional plug-in installation with detachable power cable.)
- Switchex® LED Dimmer/Power Supply
(Switchex® mounts in a standard in-wall switch box, accepts 120 Vac and converts to low voltage dc.)
The benefits of this set are:
- Blade profile, 78 3/4" (2 m) L, easily cut with a miter saw.
- Blade profile dimensions: 13/16" (21 mm) W x 3/8" (10 mm) H.
- FlexyLED UHE6B PW is a LED strip with 280 LED/m on a circuit 1/4" (6 mm) W.
- FlexyLED UHE6B PW available in fixed lengths (trimmable): 19 11/16" (500 mm), 39 3/8" (1000 mm), 59 1/16" (1500 mm), 78 3/4" (2000 mm).
- Kits recommended for a 96" counter.
- 78" power cable is pre-wired to the FlexyLED UHE6B PW.
- Extension cables are available in 20", 40" and 78".
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen, Living Room, Commercial, Furniture
Compatibility: Micro 24
Control System: Bluetooth / Dimmer
Finish: Aluminum
Group: LED Group A, LED 24 V dc Exclusive
Kelvin Color Temperature ( K): 4000 K
Lighting: Accent, Task
Lighting Type: LED
Location: Under Cabinet
Luminaire: Rigid Linear
Mounting: Recessed
Operation: Smart Technology (Bluetooth) / Wall
Product #: WEBKIT1245769
Product №: WEBKIT1245769
Style: Contemporary
Tension ( V): 24 V
Watts: 5 W
