Richelieu WEBKIT1246078 BASKI LED Drawer Cabinet Starter GuideRichelieu WEBKIT1246078 BASKI LED Drawer Cabinet - Starter Guide enhances your kitchen with efficient lighting designed specifically for base units. This innovative LED fixture features a built-in sensor that automatically turns the light on and off when cabinet doors are opened and closed, providing convenience and energy savings. The Baski is available in two sleek finishes-aluminum and black-and comes in fixed lengths of 18", 24", 30", 36", and 48", allowing you to choose the perfect size for your cabinetry. It is compatible with Micro 24 connection types and operates at a voltage of 24 V, with a luminous efficiency of 85 lm/W. With a color rendering index (CRI) of 80 and a color temperature of 4000 K, it delivers bright, natural lighting that enhances the visibility of your kitchen tasks. Installation is straightforward thanks to the included pre-wired 78" power cable, and extension cables are available in 20", 40", and 78" lengths. While the Baski is designed for indoor cabinet spaces, it is essential to adhere to local electrical codes during installation. Make your kitchen functional and stylish with the Richelieu Baski LED system, where contemporary design meets practicality.
BASKI LED Drawer Cabinet - Starter Guide
Control type:
- Built-in Sensor
The benefits of this set are:
- Baski is an LED designed for application in kitchen base units.
- The profile integrates one sensor to switch it on and off automatically when the door is opened and closed.
- It is installed on the side of the frame with thicknesses of 5/8", 23/32", 3/4" (16mm, 18mm, 19mm).
- Available in two finishes: aluminum and black.
- Available in fixed lengths: 18" (457 mm), 24" (609 mm), 30" (762 mm), 36" (914 mm), 48" (1219 mm).
- Includes a pre-wired 78" power cable.
- Extension cables are available in 20", 40" and 78".
- Recommended to only go a distance of 24-ft from the light to the power supply.
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Important information
WARNING:
Product installation must be done in accordance with local electrical codes, please confirm with an electrician or inspection office.
Attributes
Application: Kitchen
CRI ( Color Rendering Index): 80
Compatibility: Micro 24
Connection Type: Micro 24
Control System: IR
Finish: Aluminum
IP: IP20
Kelvin Color Temperature ( K): 4000 K
Length: 30 in*
Lighting: Task, Functional
Lighting Type: LED
Location: Inside Cabinet
Luminaire: Rigid Linear
Luminous Efficiency: 85 lm/W
Operation: Door
Product #: WEBKIT1246078
Standards and Certifications: UL, ETL
Style: Contemporary
Tension ( V): 24 V
Watts: 6.2 W
