Richelieu WEBKIT1248910 AVENTOS HKi Semi-Recessed Set, No HandleRichelieu WEBKIT1248910 AVENTOS HKi Semi-Recessed Set Without Handle offers an innovative lifting mechanism that seamlessly integrates into your cabinetry, paving the way for high-end design possibilities. This compact and narrow mechanism features an ultra-thin cover that maintains the aesthetic integrity of your furniture while enhancing functionality. Designed for frameless cabinet models, this lift-up opening system accommodates wood doors with a thickness ranging from 5/8 to 31/32 inches and supports door weights of up to 39.7 pounds. The AVENTOS HKi is equipped with advanced motion technology, including soft-close and touch release features, ensuring a smooth and effortless operation. Key advantages include a force reservoir adjustment located at the front, an integrated opening angle limiter, and a continuous stop for added convenience. With a power factor range of 2,600 to 7,800, this system allows you to customize the force reservoir according to your cabinet's specific needs. For optimal performance, especially in wider cabinet bodies, consider adding an extra force reservoir to an intermediate side panel to counteract front flexing. This thoughtful design invites you to explore limitless arrangement possibilities while maintaining a clean, sophisticated look in any space.
AVENTOS HKi Semi-Recessed Set Without Handle
Compact and Narrow Mechanism, Ultra-Thin Cover
AVENTOS HKi integrates partially into the side of the cabinet body. The lift mechanism fitting thus blends seamlessly into the furniture, opening up new possibilities for high-end aesthetic designs. You achieve a pure piece of furniture and total freedom of arrangement.
Some advantages:
- Force reservoir adjustment at the front
- Integrated opening angle limiter
- Continuous stop
Note:
The power factor allows you to determine the appropriate force reservoir. The power factor depends on the weight of the front (double the weight of the handle included) and the height of the cabinet body. If a third force reservoir is used (increasing the power factor by up to 50%), we recommend a test installation.
For wide cabinet bodies, we recommend attaching an additional force reservoir to an intermediate side panel due to the flexing of the front in the open position. We recommend conducting a test installation when the values for each force reservoir are at the limit of the allowable values!
Attributes
Brand: Blum
Cabinet Model: Frameless
Compatible with aluminum frame doors: Yes
Door Height: Max. 23 5/8 in*
Door Length: Max. 70 7/8 in*
Door Thickness: 5/8 to 31/32 in*
Door Type: Wood Door
Door Weight: Max. 39.7 lb*
Finish: Light Gray
Model: Aventos HKi
Motion Technology: Soft-Close, Touch Release
Opening Types: Lift-Up Opening
Power Factor: 2 600 to 7 800
Product #: WEBKIT1248910
