Richelieu WEBKIT1248936 AVENTOS HKi Recessed Set, No HandleRichelieu WEBKIT1248936 AVENTOS HKi Recessed Set Without Handle offers a sleek and modern solution for enhancing cabinet functionality while maintaining aesthetic appeal. This compact and narrow mechanism is designed to integrate seamlessly into the side of your cabinet body, allowing for a clean, unobtrusive look. Ideal for high-end designs, it opens up a world of creative possibilities in furniture arrangement. One of the standout features of this lift mechanism is its force reservoir adjustment at the front, enabling precise control based on your cabinet's specifications. The integrated opening angle limiter and continuous stop further enhance usability, ensuring smooth operation. Suitable for frameless cabinet models, this mechanism accommodates door thicknesses ranging from 5/8 to 31/32 inches and supports door weights of up to 39.7 pounds. The AVENTOS HKi features soft-close and touch release motion technology, providing a gentle and effortless opening experience. Finished in carbon black, it complements a variety of styles while maintaining durability. Keep in mind that for wider cabinet bodies, an additional force reservoir may be necessary to prevent flexing of the front when open. For the best results, a test installation is recommended, especially when nearing the limits of the allowable values.
AVENTOS HKi Recessed Set Without Handle
Compact and Narrow Mechanism, Ultra-Thin Cover
AVENTOS HKi integrates entirely into the side of the cabinet body. The lift mechanism fitting thus blends seamlessly into the furniture, opening up new possibilities for high-end aesthetic designs. You achieve a pure piece of furniture and total freedom of arrangement.
Some advantages:
- Force reservoir adjustment at the front
- Integrated opening angle limiter
- Continuous stop
Note:
The power factor allows you to determine the appropriate force reservoir. The power factor depends on the weight of the front (double the weight of the handle included) and the height of the cabinet body. If a third force reservoir is used (increasing the power factor by up to 50%), we recommend a test installation.
For wide cabinet bodies, we recommend attaching an additional force reservoir to an intermediate side panel due to the flexing of the front in the open position. We recommend conducting a test installation when the values for each force reservoir are at the limit of the allowable values!
Attributes
Brand: Blum
Cabinet Model: Frameless
Compatible with aluminum frame doors: Yes
Door Height: Max. 23 5/8 in*
Door Length: Max. 70 7/8 in*
Door Thickness: 5/8 to 31/32 in*
Door Type: Wide Aluminum-Framed Door / Narrow Aluminum-Framed Door (20 mm and Less)
Door Weight: Max. 39.7 lb*
Finish: Carbon Black
Motion Technology: Soft-Close, Touch Release
Opening Types: Lift-Up Opening
Power Factor: 930 to 2 800
Product #: WEBKIT1248936
