Richelieu WEBKIT1249707 AVENTOS HS Top Kit - CanadaRichelieu WEBKIT1249707 kits AVENTOS HS top -Canad offers a compact and efficient solution tailored for large, single-piece facades. This innovative system enables a smooth, effortless opening mechanism, allowing doors to tilt gracefully above the cabinet. Enjoy a weightless sensation and enhanced freedom of movement, making it ideal for spaces where functionality and aesthetics are paramount. Designed for cabinet heights ranging from 350 to 800 mm (13 3/4 in - 31 1/2 in) and widths up to 1,800 mm (70 7/8 in), the AVENTOS HS top accommodates substantial door weights between 7.72 to 40.8 lb. Its minimum interior depth of 264 mm (10 3/8 in) ensures compatibility with various cabinet designs. The integrated BLUMOTION damper adjustment provides minimal resistance forces and a continuous stop for ease of use. With tool-free assembly and two types of force reservoir mounting, installation is straightforward. The 3-dimensional face adjustment ensures a perfect fit, while the design allows for complete access to the interior without obstructing workspace. For narrow aluminum-framed doors, consider the 20S42T1 front attachment for optimal integration. Experience the perfect blend of style and practicality with Richelieu's AVENTOS HS top.
kits AVENTOS HS top -Canad -
A compact and functional solution for large doors
Designed for large, single-piece facades, AVENTOS HS top ensures smooth and effortless opening. The door tilts gently above the cabinet, offering a weightless sensation and unparalleled freedom of movement.
Product highlights:
- Ideal for large single-piece facades
- Cabinet height from 350 to 800 mm (13 3/4 in - 31 1/2 in)
- Cabinet width up to 1,800 mm (70 7/8 in)
- Minimum interior depth of cabinet body: 264 mm (10 3/8 in)
- Integrated BLUMOTION damper adjustment
- Minimal resistance forces
- Continuous stop
- Fixed position for the force reservoir and front attachment
- Symmetrical force reservoirs and arms
- Tool-free assembly
- Two types of force reservoir mounting
- 3-dimensional face adjustment
Thanks to its opening outside of the movement range, access to the interior is complete, without encroaching on workspace. Without a cross stabilizer, it maximizes storage capacity while seamlessly integrating into designs for optimized space and controlled ergonomics.
For thin facades, use the 20S42T1 front attachment, which can be found among the suggested products.
Attributes
Brand: Blum
Compatible with aluminum frame doors: Yes
Door Height: 25 5/8 to 31 1/2 in*
Door Length: Max. 70 7/8 in*
Door Type: Narrow Aluminum-Framed Door (20 mm and Less)
Door Weight: 7.72 to 40.8 lb*
Finish: Pale Grey
Minimum internal depth of the enclosure: Min. 10 3/8 in*
Model: Aventos HS Top
Opening Types: Up and Over Opening
Product #: WEBKIT1249707
Screw/ Nail: Wood Screw (Included)
