Richelieu WEBSO1248266 Olympia Hinge offers a sophisticated solution for your door installations, combining functionality and style. Designed with a 5-speed adjustable damper, this hinge allows for smooth and controlled door movement, enhancing user experience in both residential and commercial settings. The 3-way adjustment feature simplifies installation, ensuring a perfect fit once the door is mounted. With a robust load capacity of 6 kg per two hinges, the Olympia is suitable for a variety of applications, accommodating both wood and glass doors. It is compatible with wood door thicknesses ranging from 15 to 20 mm and glass door thicknesses of 4 to 6 mm. The hinge opens to an impressive angle of +105°, providing ample access while maintaining sleek aesthetics. Crafted for frameless cabinet types, the Olympia hinge employs a screw-on fixing type for secure installation. Its soft-closing mechanism ensures a gentle and quiet closure, making it an excellent choice for high-traffic areas. Additionally, the milling depth of 7/16 inches and diameter of 1 3/8 inches are designed for seamless integration into your cabinetry. With the Olympia Hinge, you can elevate the functionality and style of your door systems effortlessly.
Olympia Hinge
Brand: Sugatsune
Cabinet Type: Frameless
Closing Mechanism: Soft-Closing
Door Position: Overlay
Door Thickness: 19/32 to 25/32 in*
Fixing Type: Screw-On
Hinge Opening Angle: +105°
Load Capacity: 13.2 to 22 lb*
Mechanism: Soft-Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Overlay: 9/16 in*
Product #: 360-D26-14T
Production Time: Special Online Order
Use Type: Standard Door, Glass
