Safety Tech UB-1PN Universal Button Pneumatic Timer Switch

Safety Tech Intl Inc UB-1PN Universal Button Pneumatic Timer Switch is a versatile and efficient solution for access control applications. This pneumatic push button switch features a remarkable design that offers over 200 combinations within a single kit, making it adaptable to various needs and environments. The adjustable pneumatic timer allows users to open or close a circuit with a timed delay before reset, providing seamless operation. With a timer range of 2 to 60 seconds (± 15%) and a repeat accuracy of ± 10%, you can rely on this switch for precise timing without the need for powered operation. Its Form "Z" contacts include one normally open (N.O.) and one normally closed (N.C.) configuration, ensuring compatibility with a variety of systems. Designed for durability, the faceplate is constructed of cast aluminum, providing a robust and long-lasting finish. This switch is rated for 10 amps (resistive) at 240 VAC, ensuring it can handle demanding applications. Additionally, it meets ADA requirements, making it accessible for all users. Ideal for both residential and commercial settings, the Safety Tech UB-1PN combines performance and reliability, making it an excellent choice for your access control needs.

Universal Button Pneumatic Timer Switch

• Pneumatic push button
• Offers over 200 combinations in one kit
• Pneumatic adjustable timer opens or closes a circuit and has a timed delay before reset
• Pneumatic timer range: 2-60 seconds (± 15%). Repeat accuracy is ± 10%
• Power not required for timing operation
• Form "Z" contacts, one N.O., one N.C.
• Switch rating 10 amp. (resistive) 240 VAC
• Faceplate constructed of cast aluminum
• ADA for operation

Features

• Offers over 200 combinations in one kit
• Switch rating 10 amp. (resistive) 240 VAC
• Pneumatic timer range: 2-60 seconds (± 15%). Repeat accuracy is ± 10%
• ADA for operation
• Faceplate constructed of cast aluminum
• Power not required for timing operation
• Pneumatic push button
• Form "Z" contacts, one N.O., one N.C.
• Pneumatic adjustable timer opens or closes a circuit and has a timed delay before reset
