Sargent 3010XG04LB10BE F86 Grade 1 Cylindrical Lever Lock, B Lever, L Rose, Dark Bronze Finish

Sargent 3010XG04LB10BE Storeroom or Closet (F86) Cylindrical Lever Lock Grade 1 is designed to provide robust security and reliability for commercial applications. This model features a sleek B Lever and L Rose, finished in a sophisticated dark bronze. With a 2-3/4" backset, it is ideal for doors ranging from 1-3/4" to 2" thick, ensuring a secure fit in various settings. Engineered to exceed industry standards, the Sargent 3010XG withstands over 3,100 in-lb locked lever torque, significantly surpassing ANSI/BHMA A156.2 requirements. It can endure up to 1,600 lbs of offset lever pull and maintains latch retraction under a 100 lb preload, ensuring dependable operation even in warped doors or those with latch bind. Additionally, it has been rigorously tested to survive over 20 million cycles, affirming its durability. The lockset includes an ASA strike with dimensions of 4-7/8" and a 1-1/4" lip, and features a latch faceplate dimension of 1-1/8" x 2-1/4". With UL and cUL listings for a 3-hour fire rating, the Sargent 3010XG is a trusted choice for storerooms and closets, backed by a 7-year limited warranty.

Storeroom or Closet (F86) Cylindrical Lever Lock Grade 1 with B Lever and L Rose with Schlage Prep and ASA Strike Dark Bronze Finish

SARGENT Manufacturing Company, an ASSA ABLOY Group company, was founded in the early 1800s and is a leading manufacturer of architectural hardware and locking products for new and retrofit applications. SARGENT products are installed in many types of buildings, including commercial, healthcare, industrial and educational, and are "key" to the security of them all.

• Prevents entry and maintains egress against more than 3,100 in-lb locked lever torque (2.6x ANSI/BHMA A156.2 requirements)
• UL Cycle Above and Beyond test completed at 20 million cycles (Verification ID: V584148)
• Ensures latch retraction with 100 lb preload (2x ANSI/BHMA A156.2) while maintaining operation in warped doors or doors with latch bind
• Withstands 1,600 lbs offset lever pull (8x ANSI/BHMA A156.2 requirements) and continues to restrict entry
• Prohibits entry after more than 100 vertical impacts (20x ANSI/BHMA A156.2 requirements)
