Sargent & Greenleaf 2006-108 Titan Pivotbolt Keypad Chrome

Sargent & Greenleaf 2006-108 Titan Pivotbolt Keypad Chrome offers a formidable level of security for your safe, designed with a robust, 10-user electronic lock system. Its cutting-edge locking mechanism utilizes a motorized blocking device, ensuring enhanced durability and reliability even under heavy use. The Titan lock is rigorously tested to meet high EMP impact standards, providing added peace of mind against electronic threats. This lock features a user-friendly code management system, accommodating one master code, one supervisor code, and seven user codes, all field programmable from the keypad. The Titan also includes a time-delay override code and can withstand up to 225 lbs. of bolt end pressure, making it ideal for applications requiring robust bolt work blocking. With versatile mounting options-universally handed for left, right, up, or down installation-the Titan adapts to various safe configurations. Its motor-blocking bolt operation allows for three modes of use: single, dual, or manager/employee. The lock also features a low battery signal and can achieve up to 10,000 openings on a single 9V battery. Backed by a leading two-year warranty, the Sargent & Greenleaf Titan Pivotbolt Keypad is a reliable choice for securing your valuables with style and strength.

Titan Pivotbolt Keypad Chrome

The Titan is a robust, 10-user electronic safe lock with a completely redesigned locking mechanism based on the proven security of a motorized blocking device. Built to withstand heavy use, Titan performs with exceptional durability and the motor-driven locking mechanism delivers an extra measure of security. Titan is tested to the highest EMP impact standard. Regardless of attack or conditions, our EMP-resistant electronic gun safe lock keeps your assets secure. An optional bolt position indicator module allows you to integrate Titan with other security systems.

Features:

• Proven Security: The Titan lock is a robust, 10-user lock with a completely redesigned locking mechanism based on the proven security of a motorized blocking device.
• Rugged Design: Built to withstand heavy use, even with additional bolt work or locking bars, Titan performs with exceptional durability. A motor-driven locking mechanism delivers an extra measure of security and longer battery life.
• Best-In-Class Warranty: Sargent and Greenleaf backs Titan locks with a leading two-year warranty and exceptional service.
• Automatically re-locks to secure the safe whenever the container’s bolt work moves to the fully closed position
• Lock bolt retraction and extension is controlled by the movement of the safe’s bolt work
• Withstands 225 lbs. of bolt end pressure for a high level of security in bolt work blocking applications
• Stainless steel lock bolt

Specifications:

• Code Management:
• One master code, one supervisor code, seven user codes
• Management reset code
• Time-delay override code
• One million codes available
• Field programmable from keypad
• Lock Installation:
• Standard S&G magic module footprint
• Universally handed: left hand, right hand, up, or down mounting
• Operation:
• Motor-blocking bolt operation
• Three modes of operation: single user, dual user, or manager/employee mode
• Penalty lockout after five failed attempts
• Time delay 99 minutes (1-15 minute opening window)
• Tested up to 10,000 openings on one 9V alkaline battery
• Low battery signal
• Keypad Options:
• Bolt position indicator
• Available in one-battery keypad, two-battery keypad, non-rotating low profile keypad (direct drive available in low profile rotating keypad only)
• Choose from a variety of finishes - details available online
