Schlage Electronics CO100-MS-70-KP-RHO-643E-L-RH is a Grade 1 classroom/storeroom mortise lock that seamlessly combines security and convenience. Designed for commercial use, this electronic lock features a robust keypad capable of accommodating up to 500 unique users. Its manual programming allows for easy addition or deletion of PIN codes directly at the door, significantly reducing the need for mechanical keys and enhancing overall key system integrity. The lock boasts an aged bronze finish that not only provides a sophisticated look but also ensures durability. With a spring latch and a right-handed Rhodes lever design, it is both practical and stylish. The CO-100 is fire-rated for up to 3 hours, making it a safe choice for various environments. Installation is straightforward, compatible with doors that are 1-3/4 inches thick. It operates on 4 AA batteries, offering an impressive battery life of up to 2 years. With ANSI/BHMA certification and ADA compliance, this lock meets rigorous industry standards, ensuring reliability and accessibility. Choose the Schlage Electronics CO100-MS-70-KP-RHO-643E-L-RH for a dependable locking solution that enhances security while simplifying access control for your building.
Grade 1 Classroom/Storeroom Mortise Lock, Keypad, 500 Users, Less Conventional Cylinder, Rhodes Lever, Spring Latch, Aged Bronze Finish, Right-Handed
The CO Series is the ideal solution for customers seeking the added security and convenience of electronic access control without the cost or complexity of a fully networked system. The CO-100 is a standalone lock that is manually programmable. User rights for the CO-100 are stored on the lock. Unique PIN codes can be assigned to each user. This minimizes the number of mechanical keys issued which protects the integrity of your key system. PIN codes can be easily added or deleted at anytime, right at the door.
Attributes
Accessible: Yes
Ada Compliance: Yes
Amp Draw: 250 mA
Ansi: ANSI/BHMA A156.25 (full outdoor), A156.13 Series 1000 Grade 1
Base Material: Steel
Battery Life: 2 Years
Bolt Projection: 3/4"
Bolt Throw: 3/4"
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Less Conventional Cylinder
Design A: RHO - Rhodes Lever
Door Thickness: 1-3/4"
Dust Box: Plastic
Finish: 643E/US11E
Finish Description: 643E/US11E
Finish Family: Dark Bronze
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 70-Classroom/Storeroom
Function Family: Storeroom
Grade: Grade 1
Handing: Right-Handed
Installation: Commercial
Keypad Type: Pushbutton
Latch Backset Dim: 2-3/4"
Latch Backset Dimension: 2-3/4"
Leverknob Design: RHO - Rhodes Lever
Leverknob Design Family: Straight Return Lever
Limited Warranty: 2 Years
Lock Platform: Mortise Lock with Keypad
Operating Voltage: 4 to 7 VDC
Origin: Mexico
Pack Qty: 1
Pins: 6
Power: 4 AA Batteries
Projection: 2-15/16"
Reader Technology: Keypad Reader
Rose Number: 03-042 RHO 643E
Roseescutcheon Design: RHO - Rhodes
Roseescutcheon Dimensions: 3-7/16" Diameter
Screws: Combination
Series: CO Series Standalone Electronic Locks
Software Included: No
Std Latch Backset Dim: 2-3/4"
Std Latch Number: 14-049 643E
Std Latch Type: Spring Latch (Unguarded)
Std Strike Height: 1-1/4"
Std Strike Number: 10-072 643E
Std Strike Type: Mortise Strike
Std Strike Width: 4-7/8"
Subtype: Mortise Locks with Keypad Trim
Type: Integrated and Pushbutton
Ul Listing: UL 294, ULC S319, UL 10C Listed
Unit of Measure: Each
Users: 500
