Schlage ND40SRHO612 Lock Cylindrical Lock

Your Price: $487.13

Retail Price:$866.000

Your Savings:$378.87(44%)

Bath or Bedroom Privacy Lock Function, Grade 1, Cylindrical Lock, Rhodes Lever, Satin Bronze Clear Coated

Part Number : SCH_ND40SRHO612

Availability: 6 In Stock

Quantity

Description

Schlage ND40SRHO612 Lock Cylindrical Lock

Push-button locking. Can be opened from outside with small screwdriver. Turning inside lever or closing door releases button.

Handing: All ND-Series lever locksets are non-handed.
Door Thickness:
1-5/8" to 2-1/8" (41mm–54mm) standard including Vandlgard® functions.
1-3/4" - 2" for function ND85.
Backset: 2-3/4" (70 mm) standard. 2-3/8", 3-3/4" and 5" (60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 1-1/8" x 2-1/4" (29 mm x 57mm) square corner, beveled.
Lock Chassis: Zinc plated for corrosion resistance.
Latch Bolt: Steel, 1/2" (12mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Levers: Pressure cast zinc, plated to match finish symbols.
Roses: Brass, bronze or zinc.
Strike: ANSI curved lip strike 1-1/4" x 4-7/8" x 1-3/16" lip to center standard. Optional strikes, lip lengths and ANSI strike box available.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
No access with minimum 3,100 in-lbs of lever torque (2.6x BHMA, for general abuse)
No access with minimum 1,600 lbs of offset lever pull (8x BHMA, for pry-bar attacks)
No access with minimum 100 vertical impacts (20x BHMA, for sledgehammer attacks)
Near-zero droop and wobble beyond 16 million cycles (after 16x BHMA) – without the use of set screws or O-rings
Latch retraction with up to 200 pound preload (4x BHMA) for confident operation in warped and preloaded doors
Cast steel spindle construction exceeding 16 million cycles
Withstood aggressive Schlage development testing including lever-snap and abusive cycling
31 mechanical functions
6 wired functions with:
Autodetecting 12-24V DC input
Switch-selectable EL/EU operation
Modular request to exit (RX)
0.230A max/0.010A holding current
Available in 10 finishes, 5 lever designs, and 2 rose designs
Multiple key systems available – open, patented, restricted, geographic exclusive, UL437
Support for 10 non-Schlage cylinders including Best, Corbin Russwin, Medeco, Sargent and Yale
Certifications: Exceeds BHMA A156.2 requirements for grade 1 cylindrical locks. Exceeds BHMA A156.25 requirements for indoor electrified locks.

Attributes

Accessible: Yes

Ada Compliance: Yes

Alternate Codes: 133276, D40SRHO612, ND40SRHO612

Ansi: ANSI A156.2 Series 4000, Grade 1

Ansi Function: F76 - Privacy

Ansi Function Description: Privacy

Baa Qualified: Yes

Backset: 2-3/4"

Bolt Projection: 1/2 In.

Bolt Protection: 1/2"

Bore Hole Diameter: 2-1/8 In.

Box Depth Fraction: 9-1/2 In.

Box Height Fraction: 4-3/4 In.

Box Width Fraction: 8-1/4 In.

Category: Commercial Locks, Cylindrical Levers, Lock Sets

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Cylinder Included: No

Cylinder Type: Non-Keyed

Cylinders Present: Non-Keyed

Door Application: Cylindrical Levers

Door Bore Size: 2-1/8"

Door Thickness: 1-5/8" - 2-1/8"

Door Thickness Max: 2-1/8"

Door Thickness Min: 1-5/8"

Finish: 10, 612, US10

Finish Code: 612

Finish Color: Satin Bronze

Finish Description: Satin Bronze Clear Coated

Finish Family: Matte Bronze

Fire Rated: Yes

Fire Rating: 180 min

Function: 40-Bed Bathroom Privacy Lock

Function Family: Privacy

Grade: Grade 1

Hand: Not Handed

Handing: Non-handed

Installation: Commercial

Knob/ Lever Design: Rhodes

Knob/ Lever Style: Lever

Latch Backset Dim: 2-3/4 In.

Latch Bolt Face Type: Square Corner

Latch Bolt Faceplate Size: 2-1/4" x 1-1/8"

Latch Bolt Throw: 1/2"

Latch Bolt Type: Springlatch

Latch Bore Diameter: 1 In.

Latch Number: 13-248

Latch Type: Spring Latch (Unguarded)

Lever Design: Rhodes

Lever Knob: Lever

Lever Knob Design: RHO - Rhodes

Lever Knob Design Family: Straight Return Lever

Lever Knob Design Name: Rhodes

Leverknob Design: RHO - Rhodes Lever

Leverknob Design Family: Straight Return Lever

Limited Warranty: 10 Years

Lock Category: Cylindrical Lock

Lock Face Size: 2-1/4 In. x 1-1/8 In.

Manufacturer Function: Bath/Bedroom Privacy Lock

Manufacturer Function Description: Push-button locking. Can be opened from outside with small screwdriver. Turning inside lever or closing door releases button. Inside lever is always free for immediate egress.

Maximum Door Thickness: 2-1/8 In.

Minimum Door Thickness: 1-5/8 In.

Origin: Mexico

Pack Height: 4.75"

Pack Height 2: 10"

Pack Length: 9.5"

Pack Length 2: 16.38"

Pack Qty: 1

Pack Volume: 372.28 in³

Pack Volume 2: 2394.84 in³

Pack Width: 8.25"

Pack Width 2: 14.63"

Product Height: 3.44"

Product Length: 6.28"

Product Width: 2.94"

Projection: 2-15/16 In.

Restricted Keyway: No

Rose Escutcheon: Rose

Rose Escutcheon Design: 3-7/16 In. Diameter

Rose Escutcheon Dimensions: 3-7/16"

Rose/ Escutcheon Size: 3-7/16"

Rose/ Escutcheon Style: Rose

Roseescutcheon Design: 3-7/16" Rose Diameter

Roseescutcheon Dimensions: 3-7/16"

Screws: Combination

Series: ND

Ship Weight: 5 lbs.

Std Latch Backset Dim: 2-3/4 In.

Std Latch Number: 13-248

Std Latch Type: Springlatch

Std Strike Height: 4-7/8 In.

Std Strike Number: 10-025

Std Strike Type: ANSI Strike

Std Strike Width: 1-1/4 In.

Strike Dimensions: 1-1/4 In. x 4-7/8 In.

Strike Height: 4-7/8"

Strike Number: 10-025

Strike Size: 4-7/8" x 1-1/4"

Strike Type: ASA

Strike Width: 1-1/4"

Structure Function: 40

Structure Latch: S

Structure Latch Number: 13-248

Structure Outside Finish: 612

Structure Outside Trim: RHO

Structure Series: ND

Structure Strike Number: 10-025

Subtype: Cylindrical Lock

Supplier: Schlage

Type: LOCK SETS

Ul Listing: UL/cUL Listed

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 6
