Ship via: Can Ship UPS
Alternate Codes: ND94JDLAT626, SCHND94JDLAT626
Ansi Function: F84 - Classroom
Baa Qualified: Yes
Backset: 2-3/4" Backset
Bolt Protection: 1/2"
Category: Commercial Locks, Cylindrical Levers, Lock Sets
Country of Origin: Mexico
Cylinder Type: Schlage FSIC Less Core
Design: Latitude
Door Application: Cylindrical Levers
Door Thickness: 1-5/8 In. - 2-1/8 In.
Finish: 626/US26D
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Finish Description: Satin Chromium Plated
Fire Rated: Yes
Fire Rating: 180 min
Function: 94-Classroom Lock
Grade: Grade 1
Hand: Not Handed
Latch Backset Dim: 2-3/4 In.
Latch Number: 13-247
Latch Type: Dead Latch (Guarded)
Lever Design: Latitude
Lever Knob Design: LAT - Latitude
Limited Warranty: 3 Years
Lock Face Size: 2-1/4 In. x 1-1/8 In.
Rose Escutcheon Design: 3-7/16 In. Diameter
Screws: Combination
Series: ND
Strike: ASA Strike
Strike Height: 4-7/8"
Strike Number: 10-025
Strike Type: ASA
Strike Width: 1-1/4"
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
