Schlage ND96PDEU ATH 625 RX Gr1 Vandlgard Storage Fail-Safe

Schlage ND96PDEU ATH 625 RX Gr1 Vandlgard Storerm, Fail Sec is a Grade 1 electrified cylindrical lock designed for high-security storeroom applications. This lock features a storeroom function with Vandlgard, ensuring safety and reliability. Operating on a 12-24V DC power supply, it is fail secure, maintaining locked status during power outages. The ND Series locks are UL Listed and suitable for both fire and electrical single-point locking on labeled doors. With its robust design, it excels in high-traffic areas where continuous operation is essential. The auto-detecting capability for 12-24VDC input allows for seamless integration into existing systems, while the low 0.23 amp maximum current draw supports multiple locks on a single power supply. The lock includes a modular Request to Exit (RX) feature, enhancing its versatility for various applications. Designed for commercial use, it accommodates door thicknesses of 1-3/4" to 2" and can be easily installed in new constructions. Its stylish Athens lever and bright chrome finish add a touch of sophistication, making it an ideal choice for any modern facility. With a one-year limited warranty, the Schlage ND96PDEU ensures peace of mind alongside its top-notch performance.

Gr1 Vandlgard Storerm,Fail Sec

Grade 1 Electrified Cylindrical Lock, Storeroom Function with Vandlgard, 12-24V DC, Fail Secure, 2-3/4" Backset, RX, Athens Lever, Bright Chrome

ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.

Electrified Schlage cylindrical locks offer superior energy efficiency and flexibility in wired electrified applications.

Wired electrified locks complement the mechanical offering and are typically incorporated into a wired access control system or used independently with a remote access switch.

Applications

The electrified ND is ideally used in:

• High traffic areas, where line power ensures continuous operation
• New construction, where electrified door prep, hinges and wiring can easily be incorporated into the building

Key Features

All mechanical features plus:

• Auto-detecting 12-24VDC input
• Selectable EL/EU operation
• Low 0.23 amp max current draw that allows multiple locks on a single power supply
• Low 0.010 amp holding current that eliminates "hot levers" in electrically locked applications
• Modular Request to Exit (RX) that can be added at any time
• Inventory friendly–one lock supports 12-24V, EL or EU, with or without RX
• Six electrified functions for application flexibility
