Ansi: 10C
Baa Qualified: Yes
Base Material: Brass
Burglar Rated: No
Commercial Residential: Commercial
Connector Type: ElectroLynx™|No Connector
Country of Origin: Usa
Country of origin: USA
Depth: 1.03
Endurance: 1,000,000
Finish: 606 Satin Brass, clear coated
Finish Description: Satin Brass
Finish Family: Matte Brass
Fire Rated: Yes
Fire Rating: 3 Hours
Grade: Grade 1
Height: 9
Hinge Size: 5 inches or less up to 180 degree swing range 5.5 inches up to 130 degree swing range 6 inches Butt Hinge up to 110 degree swing range 0.75 inches Offset Pivot up to 110 degree swing range
Installation: Commercial
Limited Warranty: Lifetime
Number of Wires: 12
Number of Wires Range: 0, 9, 10 or 12
Origin: USA
Pack Qty: 1
Power Transfer: 2-18GA and 8-22GA
Product Height: 1.44"
Product Length: 9.03"
Product Width: 1.19"
Restrictions: None
Series: Securitron Power Transfers
Ship Weight: 2.4 lbs.
Subtype: Electronic Parts
Type: Electronics
Ul Listing: 10C,ULC-S318
Unit of Measure: Each
Upc: 784607040217
Weather Resistance: Indoor/Outdoor
Width: 1.2
Windstorm Resistant: Yes
