Manufacturer surcharge: $ 0.0
Alt Part No: 257050
Category: Maglocks
Commercial Residential: Commercial
Current 12v DC (m A): 515
Current 24v DC (m A): 325
Finish: 628 Satin aluminum, clear anodized
Finish Description: Satin Aluminum Clear Anodized
Finish Family: Matte Silver
Fire Rated: Yes
Function: Electrically Locked (Fail Safe)
Grade: Grade 2
Holding Force (lbs): 1200
Installation: Commercial
Length: 0.0
Magnet Depth (in): 2.5
Magnet Height (in): 2.5625
Magnet Length (in): 11.5
Maximum Operating Temperature (° F): 110
Minimum Operating Temperature (° F): 32
Monitoring Options: BondSTAT Monitor & Door Position Switch
Operating Voltage: 12VDC/24VDC
Options: PIR Request to Exit
Outdoor Rated: No
Preload Capable: Yes
Sales Unit: EA
Series: Securitron Smart Magnalocks
Ship Weight: 8 lbs.
Subtype: Maglock
Switch Type: MBS/DPS
Type: Electric Strikes, Bolts, Magnets
Unit of Measure: Each
Upc: SEC100M680EBDX628
Voltage: 12/24
