Securitron V2M1200DB 1200LB Magnetic Lock with Bracket Mount

Securitron V2M1200DB 1200LB Maglock - Bracket Mount offers robust security with a formidable 1200 lbs. holding force, making it an ideal choice for high-traffic areas where durability and low maintenance are paramount. This magnetic lock features a convenient bracket mount design that includes a splice chamber, door position switch, and a bond sensor, ensuring comprehensive monitoring and control. Designed for commercial use, the V2M1200DB operates on a fail-safe function, providing peace of mind in environments where safety is critical. Its weather-resistant construction allows for reliable performance in various conditions, making it suitable for both indoor and outdoor applications. With an operating voltage of 12/24 VDC, this model is versatile enough to meet diverse installation requirements. The compact dimensions of 4-5/8" x 5/8" x 2-3/8" make it easy to integrate into existing door hardware systems. Additionally, its efficient amp draw of 520 mA/260 mA ensures effective power management without compromising on performance. Invest in the Securitron V2M1200DB for a long-lasting security solution that not only stands the test of time but also enhances the safety of your premises. With this maglock, you can trust that your access control needs are met with uncompromised reliability.

1200LB Maglock - Bracket Mount

Maglock, 1200 lbs. Holding Force, Bracket Mount with Splice Chamber, Door Position Switch and Bond Sensor

Ideal for traffic control in high-use areas where low maintenance is required.

With unsurpassed durability, Securitron magnetic locks will last long after most buildings wear out.

Securitron M32 Magnalock

• 600lbs holding force; Weather resistant

Securitron M38 Magnalock

• 600lbs holding force; Indoor use

Securitron M62 Magnalock

• 1200lbs holding force; Weather resistant

Securitron M68 Magnalock

• 1200lbs holding force; Indoor use

Securitron M82 Magnalock

• 1800lbs holding force; Weather resistant

Securitron DM62 Magnalock

• 1200lbs holding force; Weather resistant
