Accentura 546F Classroom Cylinder Trim combines robust security with versatile functionality, making it an ideal choice for educational and commercial settings. Certified to ANSI/BHMA A156.3, Grade 1, this trim is designed for durability and reliability. The 540F rose trim is specifically tailored for stock doors, ensuring a seamless fit during installation. Featuring trim thru bolts for added strength, the 546F is suitable for standard 1-3/4" (44mm) doors, with options for thicker doors available upon request. This trim accommodates cylindrical type cylinders and offers various lever trim options, including "B" for small format interchangeable cores, "M" for Medeco and ASSA large format cores, "S" for Schlage standard cylinders, and "SI" for Schlage large format interchangeable cores. The non-handed design allows for flexibility in installation. Available in a range of finishes such as Satin Chrome, Bright Brass, and Flat Black, the Accentra 546F can be customized to match any decor. Enjoy peace of mind with a 3-year limited warranty, ensuring your investment stands the test of time. Enhance your security with the reliable and stylish Accentra 546F Classroom Cylinder Trim, expertly crafted to meet your access control needs.

Exit Trim - 710-0/6100 Series Classroom, Lever x Rose, Pacific Beach Lever, 6 Pin LFIC-Yale Large Format IC Prep, Less Core, Grade 1, 626/US26D Satin Chrome

Features:

• Certified ANSI/BHMA A156.3, Grade 1.
• 540F rose trim for stock doors.
• Trim thru bolts to exit device for strength.
• 1-3/4" (44mm) door standard. For doors through 2-1/4" (57mm) or shim mounted devices, specify on order.
• AU, PB and MO trim designs.
• Accepts cylindrical type cylinders. Cylinders included, see page 50 for cylinder options.
• "B" trim prefix - Lever trim accepting all small format interchangeable cores. 6- or 7-pin (example: B-AU546F)
• "M" trim prefix - Lever trim accepting Medeco (32 series) and ASSA large format interchangeable cores. Available in AU lever only. 6-pin only. (example: M-AU546F)
• "S" trim prefix - Lever trim accepting Schlage standard cylinders. 6-pin only. (example: S-AU546F)
• "SI" trim prefix - Lever trim accepting Schlage large format interchangeable cores. 6-pin only. (example: SI-AU546F)
• Please specify when ordering 1210 LFIC prep.
• 3-year limited warranty
• 546F - Classroom cylinder controls lever

Finishes:

• 605 - Bright brass
• 606 - Satin brass
• 611 - Bright bronze
• 612 - Satin bronze
• 613E - Dark oxidized satin bronze-equivalent
• 619 - Satin nickel plated
• 625 - Bright chromium plated over nickel
• 626 - Satin chromium plated over nickel
• 629 - Bright Stainless Steel
• 630 - Satin Stainless Steel
• 693 - Flat black painted, sprayed
• BSP - Black suede powder coat, sprayed
• WSP - White suede powder coat, sprayed

Resources

• Cut Sheet
