Acorn AH2BQ 3" Smooth Offset H Hinge, Pair

Acorn AH2BQ 3" Offset Cabinet H Hinge, Smooth, Pair offers an elegant solution for your cabinetry needs. Crafted from durable steel and finished in a sophisticated matte black, these hinges not only enhance the aesthetic of your space but also provide reliable functionality. The smooth texture adds a touch of refinement, making them suitable for both modern and traditional interiors. Designed for versatility, these 3/8" offset surface mount hinges can accommodate both right and left swinging doors, ensuring flexibility in installation. When opened, the hinges measure 3" in height and 1-11/16" in width, with hinge leaves that are 0.062" thick and barrels that are 0.27" thick, providing strength and stability. This pair of hinges can support a total weight of up to 25 lbs., making them ideal for various cabinet applications. Included with the hinges are 12 #7 x 5/8" pyramid head screws for easy installation. For optimal results, it is recommended to predrill holes using a 3/32" drill bit for softwood or a 7/64" drill bit for hardwood. Hand tightening screws ensures the finish remains unblemished. Proudly made in the USA, the Acorn AH2BQ hinges are a perfect blend of quality and style for your cabinetry projects.

3" Offset Cabinet H Hinge, Smooth, Pair

AH2BQ - 3" Offset Cabinet H Hinge, Smooth, Pair

• Hinges are made from steel and finished in matte black


• Smooth texture


• 3/8" offset surface mount cabinet hinges


• Can be used for right or left swinging doors.


• Opened hinges measure 3" height x 1-11/16" width


• Hinges leaves are 0.062" thick


• Barrells are 0.27" thick


• Includes 12, #7 x 5/8" pyramid head screws, for extra screws orderAQ2B9


• Two hinges hold 25 lbs.


• Made in the USA

Installation Tips

• Predrill with 3/32" drillbit for softwood or 7/64" drillbit for hardwood.


• Hand tighten screws only, do not use power tools to porotect the finish.
