Acorn AI8BP 17-3/4" Spear Strap Hinge

Acorn AI8BP 17-3/4" Spear Strap Hinge combines robust functionality with rustic elegance, making it an ideal choice for both modern and traditional homes. Crafted from smooth iron steel and finished in Acorn's signature matte black, this hinge not only enhances the aesthetic appeal of your doors but also provides enduring strength. Designed for versatility, the AI8BP is a full surface hinge that can be mounted flush, making it suitable for both left-hand and right-hand doors thanks to its removable pins. If you prefer a half surface installation, the removable butt end allows for easy repositioning, enabling the strap to mount on the door while the butt end is mortised into the door jamb-providing a clean, seamless look when the door is closed. This hinge supports doors weighing up to 90 pounds, and for optimal installation, it is recommended to use three hinges per door. The strap measures 13" long from the barrel center to the tip of the spear and is 1-5/8" wide at the pivot point, while the butt end stands at 3-1/8" tall, all constructed with .120 gauge material. Decorative pyramid head screws for the strap and flat head screws for the butt are included, ensuring a complete and professional installation. Proudly manufactured in the USA, the Acorn AI8BP is sold individually, making it a practical choice for various applications, including interior and exterior doors, gates, and sheds.

17-3/4" Spear Strap Hinge

AI8BP - 17 3/4" Smooth Iron Black Spear Door Strap Hinge

Whether your home is new or old add some rustic charm with these timeless strap hinges. Made out of smooth iron steel shown in Acorns signature matte black finish.The pins are removable so these can be used on either left hand or right hand doors. This comes as a flush mount full surface hinge as it is. The butt end is removeable and can be positioned to be used as a half surface hinge. Meaning the strap is mounted on the door surface and the butt end is mortised into the door jamb (mostly not seen when the door is closed).

Smooth iron surface with matte black finish.

Can be used on interior or exterior doors, gates, sheds, other out buildings or projects etc.

Pins are removeable so these hinges can be used on either left or right hand doors.

To be mounted as a full surface hinge as it comes.

Butt ends are removable and can be positioned to use as half surface hinges.

For use on doors up to 90 pounds using 3 each.

Screws included- decorative pyramid head screws for strap, flat head screws for butt.

The strap is 13"Long from center of barrel to tip of spear x 1-5/8" wide at pivot point. Butt end is 3 1/8" tall.

.120 gauge.

Manufactured at our factory here in the USA.

Sold by each.
