Acorn AIJBQ 6-1/2" Smooth Heart Cabinet Strap Hinge, Flush, Pair

Acorn AIJBQ 6-1/2" Heart Cabinet Strap Hinge, Flush, Pair, Smooth offers a perfect blend of style and functionality for your cabinetry needs. Crafted from durable steel and finished in a sophisticated matte black, these hinges are designed to complement both traditional and contemporary decor. The smooth texture enhances their aesthetic appeal while ensuring seamless operation. These versatile hinges can be used for either right or left swinging doors, accommodating cabinet doors with a 3/8" offset. Each strap portion measures 6-5/8" from the center of the barrel to the end, providing robust support. With dimensions of 5/8" x 1-3/4" and a thickness of 0.062" for the leaves and 0.27" for the barrels, these hinges are built to last. Together, they can support a weight of up to 25 lbs., making them suitable for various applications. Included with the hinges are 10 #7 x 5/8" pyramid head screws to facilitate easy installation. For best results, predrill with a 3/32" drill bit for softwoods or a 7/64" drill bit for hardwoods, and remember to hand tighten the screws to protect the finish. Proudly made in the USA, the Acorn AIJBQ hinges combine craftsmanship and reliability for your cabinetry projects.

6-1/2" Heart Cabinet Strap Hinge, Flush, Pair, Smooth

AIJBQ - 6-1/2" Heart Cabinet Strap Hinge, Pair, Smooth

• Hinges are made from steel and finished in matte black


• Smooth texture


• Can be used for right or left swinging doors.


• Hinge is designed for cabinet doors with a 3/8" offset


• Strap portion is 6-5/8" long from center of barrel to end


• Hinges 5/8" x 1-3/4"


• Hinges leaves are 0.062" thick


• Barrells are 0.27" thick


• Includes 10, #7 x 5/8" pyramid head screws, for extra screws orderAQ2B9


• Two hinges hold 25 lbs.


• Made in the USA

Installation Tips

• Predrill with 3/32" drillbit for softwood or 7/64" drillbit for hardwood.


• Hand tighten screws only, do not use power tools to porotect the finish.
