Acorn TJ6BP 4-1/2" x 4-1/2" Butt Hinge

Acorn TJ6BP 4-1/2" x 4-1/2" Butt Hinge offers a blend of durability and aesthetic appeal, making it an ideal choice for residential applications. Crafted from cold-rolled steel, this hinge is designed to withstand daily use while maintaining its integrity over time. The TJ6BP features a full mortise design with square corners, ensuring a seamless fit into your doors and enhancing overall functionality. Measuring 4-1/2 inches tall and wide, this hinge incorporates five knuckles for smooth operation and extended lifespan. The flush pin design provides a polished appearance, complemented by a sophisticated matte black finish that harmonizes beautifully with other Acorn hardware. Each hinge is sold individually and includes eight 1-1/4" x #12 flat head screws for easy installation. Designed for residential strength, the TJ6BP is suitable for doors up to 90 inches, with recommendations for additional hinges based on door dimensions. Its removable pin feature offers convenient maintenance options. Made in the USA, this hinge reflects Acorn's commitment to quality craftsmanship. Elevate your space with the reliability and style that the Acorn TJ6BP Butt Hinge brings to your architectural hardware collection.

4-1/2" x 4-1/2" Butt Hinge

TJ6BP - 4-1/2"x 4-1/2" Square Corner Mortise Butt Hinge

The TJ6BP is made from cold-rolled steel for added strength with five knuckes for ease of use and length of life.  Made with a flush pin for a finished look, finished in Acorn matte black to match the rest of door hardware.

• Made of Steel with a Matte Black finish


• 4-1/2" tall x 4-1/2" wide (open)


• Sold as Single Hinge


• Residential Strength


• Full mortise design


• Removable Pin


• 8, 1-1/4" x #12 flat head screws included


• Square Corners


• 5 knuckles


• Arc Hole Pattern


• Made in the USA

Installation Tips

• Mounting: These have traditional standard square corners for mortised door butt hinges. It is recommended that three hinges be used on doors up to and including 90" with one additional hinge for each additional 30"


• Make sure you check your current hinges before making a purchase.


• General Hinge Size Selection









































  Thickness of Door	Width of Door	Hinge Size to Use
  1-1/4"	28" to 32"	3" Hinge
  1-3/8"	Up to 32"	3-1/2" Hinge
  1-3/8"	32" to 36"	4" Hinge
  1-3/4"	Up to 36"	4-1/2" Hinge
  1-3/4"	36" to 48"	5" Hinge
  2" to 2-1/2"	Up to 42"	5" Heavy Duty Commercial
