• Input:
• Input 115VAC, 60Hz, 0.6 amp.
• Access control trigger input.
• Output:
• 12VDC or 24VDC selectable outputs.
• 1.75 amp supply current.
• Two (2) Class 2 Rated power-limited outputs.
• Fail-Safe/Fail-Secure lock output (switched).
• Auxiliary power output (unswitched).
• PTC protected outputs, rated @ 2.5 amp.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
• Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when AC fails.
• Maximum charge current 0.4 amp.
• Supervision:
• AC fail supervision (form "C" contacts).
• Supervised Fire Alarm Disconnect (Latching w/reset or Non-Latching).
• Visual Indicators:
• AC input and DC output LED indicators.
• Electrical:
• Operating temperature: 0° C to 49° C ambient.
• 10.75-21.5 BTU/Hr.
• System AC input VA requirement: 69VA.
• Mechanical:
• Enclosure Dimensions (H x W x D approx.): 8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
• Product weight (approx.): 5.1 lbs. (2.31 kg).
• Shipping weight (approx.): 5.6 lbs. (2.54 kg).

Features

• Supervision:
• Input:
• Shipping weight (approx.): 5.6 lbs. (2.54 kg).
• Auxiliary power output (unswitched).
• Battery Backup:
• Visual Indicators:
• Enclosure Dimensions (H x W x D approx.): 8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
• Electrical:
• Mechanical:
• 10.75-21.5 BTU/Hr.
• Input 115VAC, 60Hz, 0.6 amp.
• Short circuit and thermal overload protection.
• Product weight (approx.): 5.1 lbs. (2.31 kg).
• AC fail supervision (form "C" contacts).
• Access control trigger input.
• AC input and DC output LED indicators.
• Supervised Fire Alarm Disconnect (Latching w/reset or Non-Latching).
• Two (2) Class 2 Rated power-limited outputs.
• Filtered and electronically regulated output.
• Automatic switch over to stand-by battery when AC fails.
• 12VDC or 24VDC selectable outputs.
• 1.75 amp supply current.
• Output:
• Fail-Safe/Fail-Secure lock output (switched).
• System AC input VA requirement: 69VA.
• Operating temperature: 0° C to 49° C ambient.
• PTC protected outputs, rated @ 2.5 amp.
• Maximum charge current 0.4 amp.
• Built-in charger for sealed lead acid or gel type batteries.
