ASI 1204-C18 Shower Rod Support for 1-1/4" Dia. Rod 18" H - Ceiling Mounted is an essential component for ensuring the stability and durability of your shower rod installations in high-traffic areas. Constructed from type 304 stainless steel with a satin finish, this support not only offers a modern aesthetic but also guarantees long-lasting performance in demanding environments such as schools, healthcare facilities, and transportation hubs. The support’s 18-inch height from the mounting surface to the center line of the rod sleeve provides optimal alignment for a functional and accessible shower experience. Its robust design features a flat exposed mounting flange that measures 3 inches in diameter and 1/8 inch thick, equipped with three countersunk holes for secure installation using 1/4 screws (not supplied). Fabricated from 1-inch diameter 20-gauge tubing, the support is designed to accommodate a 1-1/4 inch diameter shower rod, providing both strength and versatility. The heavy wall tubing sleeve is equipped with a stainless steel set screw to lock the shower rod securely in place, ensuring it withstands regular use while maintaining safety and efficiency. The ASI 1204-C18 Shower Rod Support is compliant with Buy American Act (BAA) standards and is readily available, making it a dependable choice for institutional applications. Enhance your restroom facilities with this reliable support, designed to withstand the rigors of high-traffic environments while offering easy maintenance and superior hygiene.
Shower Rod Support for 1-1/4" Dia. Rod 18" H - Ceiling Mounted
Ceiling support for 1204 Heavy Duty Shower Rod. Fabricated of type 304 stainless steel with satin finish and includes a flat exposed mounting flange, tubing and sleeve.
Support is 18" (457mm) from mounting surface to center line of rod sleeve or as modification length specified below.
Flat flange is 3" (76mm) dia. by 1/8" (3mm) thick and is provided with three (3) countersunk holes to accept 1/4 screws (supplied by others). Support tubing fabricated of 1′′ (25mm) dia. 20 gauge and sleeve is heavy wall tubing to accommodate 1-1⁄4′′ (32mm) dia. shower rod. Sleeve provided with stainless steel set screw for locking shower rod in place.
BAA: Yes
Height: 18
Lead Time: Available
Mounted: Yes
