ASI 3932 Kit for Installing thru 1/2 Thick Partitions (1 Per Flange) provides a robust solution for securely mounting grab bars in high-traffic environments. Designed for 1/2" (13mm) thick partitions, this anchor kit consists of a durable 3" (76mm) diameter plate made from alloy 18-8 stainless steel, type 304, ensuring exceptional strength and corrosion resistance. The plate’s 1/8" (3mm) thickness offers added stability, making it ideal for applications in schools, healthcare facilities, and government buildings where reliability is paramount. The exposed side of the plate features a No. 4 satin finish, delivering a sleek and professional appearance that complements any restroom aesthetic. This design not only enhances the visual appeal but also contributes to easy maintenance, as the satin finish resists fingerprints and smudges. Included in the kit are two 1/4-20 x 1/2" long Phillips pan head machine screws, ensuring easy installation and a secure fit. Each kit is specified per flange, allowing for precise installation tailored to your specific needs. With a commitment to durability, reliability, and U.S.-engineered quality, the ASI 3932 Kit adheres to ADA and code compliance standards, making it a trusted choice for facilities that prioritize safety and accessibility. This anchor kit is also BAA compliant, ensuring that you are supporting U.S. manufacturing while benefiting from high-quality materials and construction. Investing in the ASI 3932 Kit means choosing a product designed for efficiency and longevity, capable of withstanding the demands of busy environments while enhancing user experience through reliable support.
Kit for Installing thru 1/2 Thick Partitions (1 Per Flange)
Anchor for 1/2" (13mm) Thick Partition Mounted Grab Bars with Snap-On Flange Covers shall be fabricated of alloy 18-8 stainless steel, type 304, 3" (76mm) dia. plate 1/8" (3mm) thick with two (2) 1/4-20 posts welded-on. Exposed side of plate shall have a No 4 satin finish. Anchor kit shall contain (1) Plate and (2) 1/4-20 x 1/2" long Phillips pan head machine screws. Specify one (1) kit per flange.
BAA: Yes
Lead Time: Available
