Blum 08912953 110 Half Overlay Soft Close Inserta Hinge

BLUM 08912953 110 Half Overlay Soft Close Inserta is engineered for seamless functionality in cabinet design. This soft-close hinge features a half crank design and is ideal for a variety of applications, accommodating different overlay needs. Whether you're working with a 1/4", 1/2", full overlay, or inset configurations, you can select the appropriate hinge and mounting plate combination to achieve the perfect fit: for a 1/4" overlay, pair it with Hinge B071B3650 and Mounting Plate B175H710; for a 1/2" overlay, use Hinge B071B3550 with Mounting Plate B175H713; and for full overlay, the same hinge with Mounting Plate B175H710 works perfectly. Constructed with a 13mm cup depth, this hinge supports thicker doors up to 1", providing versatility for various cabinetry styles. Installation is straightforward, as screws are included with the screw-on hinges. Keep in mind that mounting plates for hinges must be ordered separately. With a limited lifetime warranty, BLUM stands behind the quality of this product, ensuring durability and performance for years to come. Elevate your cabinetry with the reliability and smooth operation that the BLUM 110 Half Overlay Soft Close Inserta delivers.

110 Half Overlay Soft Close Inserta

• Can use on thicker doors up to 1"
• Mounting Plates for Hinges must be ordered separately
• Choose Hinge and Mounting plate to attain correct overlay or inset as follows:
• Inset - Hinge B071B3750‚ Mounting Plate B175H710
• 13mm cup depth
• 1/2" Overlay - Hinge B071B3550‚ Mounting Plate B175H713
• Screws Included with screw-on hinges
• Limited Lifetime Warranty
• 1/4" Overlay - Hinge B071B3650‚ Mounting Plate B175H710
• Full Overlay - Hinge B071B3550‚ Mounting Plate B175H710
• new insertion ram for press in hinges BMZM.0040
