Corbin Russwin DL2213 606 CL6 DL2200 Single Cylinder Deadbolt offers a robust security solution, ideal for a wide range of applications. This Grade 2 single cylinder deadbolt features a solid steel construction, complemented by a hardened, free-spinning steel pin insert that ensures enhanced resistance against tampering. With a 1" throw, the DL2200 provides reliable locking performance, while its non-handed design allows for easy installation on any door. Designed for standard door thicknesses of 1-3/4", the DL2213 is compatible with various backsets, including 2-3/4" and 2-3/8". The deadbolt comes with a brass or stainless steel front and is available in a satin brass finish (606) that adds a touch of elegance to any entryway. It also includes a 6-pin LFIC prep cylinder, providing flexibility in keying options, including master keying and visual key control. This deadbolt is UL listed for fire ratings up to 3 hours and is backed by a one-year limited warranty, ensuring peace of mind for users. With its combination of durability, versatility, and aesthetic appeal, the Corbin Russwin DL2213 is an excellent choice for securing both residential and commercial properties.

DL2200 Single Cyl Deadbolt

Grade 2 Single Cylinder Deadbolt, Corbin Russwin 6-Pin LFIC Prep, Less Core, Satin Brass Finish, Non-Handed

Corbin Russwin is pleased to introduce the DL2200 and DL3200 cylindrical deadlocks. These easy to install deadlocks feature a solid steel deadbolt - with a hardened, free spinning, steel pin insert - and a 1" throw. Ideal for a variety of applications, the DL2200 is certified to 156.5 Grade 2 standards and the DL3200 is certified to 156.5 Grade 1 standards. Features Solid steel Deadbolt with a hardened, free spinning, steel pin insert and a 1" throw 1-3/4" door thickness standard; additional door thicknesses offered.

Comes in all standard finishes and is non-handed.

• Handing: Non-handed.
• Door Thickness: Standard - 1-3/4" (44mm). Optional door thicknesses available; see Quick Codes.
• Backset: Standard -  2-3/4" (70mm); Optional: 2-3/8" (60mm)
• Front: Standard - brass or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm). Optional: 1" width; see Quick Codes.
• Deadbolt: 1" throw, solid steel deadbolt with hardened, free spinning, steel pin insert.
• Strike: Standard - 2-3/4" (70mm) x1-1/8" (29mm). Optional strikes and wrought boxes available.
• Cylinder: Standard - brass, 6-pin, L4 keyway, 0-bitted. Security cylinder optional; see Quick Codes.
• Keys: Two nickel silver standard.
• Keying Features Available: Master keying; construction master keying; security; visual key control; concealed key control
• Warranty: One-year limited.

Resources

• DL2200/DL3200 Installation Instructions
• DL3200 Series Cylindrical Deadlocks Cut Sheet
• Padlocks and Deadlocks Catalog
