Corbin Russwin ML2030CSM613 F19 Privacy Mortise Lock with Citation Lever and M Escutcheon showcases a robust design tailored for commercial applications. This privacy lockset, part of the esteemed ML2000 Series, is crafted with a striking oil rubbed bronze finish (Finish Code: 613) that enhances both aesthetics and durability. Featuring a 2-3/4" backset, it is suitable for doors measuring 1-3/4" thick, making it a versatile choice for various installations. The lockset is equipped with a Citation Lever, which offers not only an ergonomic grip but also a sleek, modern look. Its escutcheon measures 2-1/4" x 7-1/2" and pairs beautifully with the lever's 4-3/8" projection, ensuring a secure fit and reliable performance. The ANSI straight lip strike (1-1/4" x 4-7/8") provides added stability for everyday use. With a limited 10-year warranty, the Corbin Russwin ML2030CSM613 is built to last, with UL and cUL certification for positive pressure applications, ensuring compliance with safety standards. This lockset is an excellent choice for those seeking reliability and style in a privacy function lock, ideal for offices, meeting rooms, and other private spaces.
F19 Privacy Mortise Lock with Citation Lever and M Escutcheon Oil Rubbed Bronze Finish
Ansi Function: F19 - Privacy/Bed/Bath
Baa Qualified: Yes
Backset: 2 3/4" Backset
Bolt Protection: 3/4" Latchbolt, 1" Deadbolt
Category: Mechanical Commercial Locksets
Country of Origin: Usa
Design: Citation Lever
Dimension: 4-3/8" Lever with 2-5/8" Projection and 2-1/4" x 7-1/2" Escutcheon
Door Range: 1-3/4"
Door Thickness: 1-3/4"
Finish: Oil Rubbed Bronze
Finish Code: 613
Finish Description: Dark Oxidized Satin Bronze Oil Rubbed
Fire Rated: 3 Hours {A}
Function: 30-Privacy Bedroom or Bathroom
Grade: Grade 1
Hand: Field Reversible
Hazardous Material: NO
Latch Faceplate Dimension: 1-1/4" x 8"
Lever Knob Design: CS - Citation
Limited Warranty: 10 Years
Lock Face Size: 8" x 1-1/4"
Manufacturer Warranty: Limited 10 Year Warranty
No Of Inners: 1
Order_ Qty: 1
Rose Escutcheon Design: M - Escutcheon
Screws: Combination
Series: ML2000 Series
Strike: ANSI Straight Lip Strike
Strike Dimension: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 236L72018
Strike Type: ASA
Strike Width: 1-1/4"
Subcategory: Mortise Locksets
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing Type: UL and cUL - UL10C Positive Pressure
