Corbin Russwin ML2030NSM613 F19 Privacy Mortise Lock with Newport Lever and M Escutcheon features a sophisticated oil rubbed bronze finish that combines functionality with aesthetic appeal. This mechanical commercial lockset is designed specifically for privacy applications, making it an ideal choice for restrooms or offices where secure access is essential. The lock boasts a robust 2-3/4" backset and is compatible with doors measuring 1-3/4" thick, ensuring a secure fit in various settings. Its Newport lever provides a comfortable grip, with a dimension of 4-13/16" and a 2-5/8" projection, while the M Escutcheon adds an elegant touch with its 2-1/4" x 7-1/2" profile. Crafted from durable wrought brass, this lockset promises longevity and reliability, backed by a limited 10-year warranty. Installation is straightforward, featuring an ANSI straight lip strike with dimensions of 1-1/4" x 4-7/8", and a latch faceplate measuring 1-1/4" x 8". Approved by UL and cUL for positive pressure applications, the Corbin Russwin ML2030NSM613 ensures safety and compliance for commercial environments. Choose this lockset for its blend of style, security, and ease of use.
Attributes
Accessible: Yes
Ada Compliance: Yes
Ansi Function: F19 - Privacy/Bed/Bath
Application: Complete Lock
Baa Qualified: Yes
Backset: 2 3/4" Backset
Base Material: Bronze
Bolt Projection: 3/4" Latchbolt, 1" Deadbolt
Bolt Protection: 3/4" Latchbolt, 1" Deadbolt
Category: Mechanical Commercial Locksets
Country of Origin: Usa
Country of origin: USA
Design: Newport Lever and M Escutcheon
Dimension: 4-13/16" Lever with 2-5/8" Projection and 2-1/4" x 7-1/2" Escutcheon
Door Range: 1-3/4"
Door Thickness: 1-3/4"
Finish: Oil Rubbed Bronze
Finish Code: 613
Finish Description: Dark Oxidized Satin Bronze Oil Rubbed
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 30-Privacy Bedroom or Bathroom
Grade: Grade 1
Hand: Field Reversible
Handing: Field Reversible
Hazardous Material: NO
Latch Faceplate Dimension: 1-1/4" x 8"
Lever Knob Design: NS - Newport
Leverknob Design: NS - Newport
Limited Warranty: 10 Years
Lock Face Size: 8" x 1-1/4"
Manufacturer Warranty: Limited 10 Year Warranty
Material: Wrought Brass
No Of Inners: 1
Order_ Qty: 1
Origin: USA
Pack Qty: 1
Rose Escutcheon Design: M - Escutcheon
Roseescutcheon Design: M - Escutcheon
Screws: Combination
Series: ML2000 Series
Std Strike Height: 4-7/8"
Std Strike Number: 236L72018
Std Strike Type: ASA
Std Strike Width: 1-1/4"
Strike: ANSI Straight Lip Strike
Strike Dimension: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 236L72018
Strike Type: ASA
Strike Width: 1-1/4"
Subcategory: Mortise Locksets
Subtype: Mortise
Type: Mechanical Commercial Locksets
Ul Listing Type: UL and cUL - UL10C Positive Pressure
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
