Corbin Russwin ML2055PSM613 Single Cylinder Classroom Mortise Lock with Princeton Lever and M Escutcheon combines security and style for educational and commercial settings. Designed for a 1-3/4" door, this lockset features a durable oil rubbed bronze finish that not only enhances aesthetics but also provides long-lasting wear. With a 2-3/4" backset, the ML2055 is engineered for easy installation and reliable performance. The Princeton lever design offers a comfortable grip, while the M escutcheon adds a touch of elegance. This single cylinder lock employs an L4 keyway and a 6-pin cylinder for enhanced security, making it a suitable choice for high-traffic areas. It includes an ANSI straight lip strike, ensuring proper alignment and functionality. Additional specifications include a latch faceplate dimension of 1-1/4" x 8", and a strike dimension of 1-1/4" x 4-7/8". The product is UL and cUL listed for positive pressure, meeting safety standards. Corbin Russwin backs this lockset with a limited 10-year warranty, underscoring its quality and reliability. Perfect for classroom environments, this lockset offers both security and style, making it a smart investment for any building professional or knowledgeable homeowner.
Single Cylinder Classroom Mortise Lock with Princeton Lever and M Escutcheon L4 Keyway Oil Rubbed Bronze Finish
Ansi Function: F05 - Classroom
Baa Qualified: Yes
Backset: 2 3/4" Backset
Bolt Protection: 3/4" Latchbolt
Category: Mechanical Commercial Locksets
Country of Origin: Usa
Cylinder Type: Conventional Cylinder
Design: Princeton Lever
Dimension: 5-1/4" Lever with 2-1/2" Projection and 2-1/4" x 7-1/2" Escutcheon
Door Range: 1-3/4"
Door Thickness: 1-3/4"
Finish: Oil Rubbed Bronze
Finish Code: 613
Finish Description: Dark Oxidized Satin Bronze Oil Rubbed
Fire Rated: 3 Hours {A}
Function: 55-Classroom
Grade: Grade 1
Hand: Field Reversible
Hazardous Material: NO
Keying: 0 Bitted
Keys: Blank
Keyway: L4
Latch Faceplate Dimension: 1-1/4" x 8"
Lever Knob Design: PS - Princeton
Limited Warranty: 10 Years
Lock Face Size: 8" x 1-1/4"
Manufacturer Warranty: Limited 10 Year Warranty
No Of Inners: 1
No Of Pins: 6 Pin Cylinder
Num Of Keys: 2
Num Pins: 6
Order_ Qty: 1
Rose Escutcheon Design: M - Escutcheon
Screws: Combination
Series: ML2000 Series
Strike: ANSI Straight Lip Strike
Strike Dimension: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 236L72018
Strike Type: ASA
Strike Width: 1-1/4"
Subcategory: Mortise Locksets
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing Type: UL and cUL - UL10C Positive Pressure
