Corbin Russwin ML2065CSM613LC Single Cylinder Dormitory Mortise Lock combines security and style, making it an ideal choice for educational and residential settings. This durable lockset features a sleek Citation lever, complemented by an M escutcheon, all finished in a rich Oil Rubbed Bronze, providing a sophisticated look that enhances various door designs. Designed for a 2-3/4" backset and compatible with doors measuring 1-3/4" thick, the ML2065CSM613LC ensures a secure fit and reliable operation. The lock is part of the ML2000 Series, known for its robust construction and efficiency. The ANSI straight lip strike, measuring 1-1/4" x 4-7/8", guarantees seamless installation and exceptional performance. With a limited 10-year warranty, this lockset not only meets UL and cUL standards for positive pressure but also assures long-lasting functionality. The 4-3/8" lever, with a 2-5/8" projection, is designed for user comfort, facilitating easy access while maintaining security. Perfect for dormitory environments, the single cylinder function strikes a balance between safety and convenience. Enhance your building's security with the reliable performance of the Corbin Russwin ML2065CSM613LC.
Single Cylinder Dormitory Mortise Lock with Citation Lever and M Escutcheon Less Cylinder Oil Rubbed Bronze Finish
Ansi Function: F13 - Dormitory
Baa Qualified: Yes
Backset: 2 3/4" Backset
Bolt Protection: 3/4" Latchbolt, 1" Deadbolt
Category: Mechanical Commercial Locksets
Country of Origin: Usa
Design: Citation Lever
Dimension: 4-3/8" Lever with 2-5/8" Projection and 2-1/4" x 7-1/2" Escutcheon
Door Range: 1-3/4"
Door Thickness: 1-3/4"
Finish: Oil Rubbed Bronze
Finish Code: 613
Finish Description: Dark Oxidized Satin Bronze Oil Rubbed
Fire Rated: 3 Hours {A}
Function: 65-Dormitory or Entrance
Grade: Grade 1
Hand: Field Reversible
Hazardous Material: NO
Latch Faceplate Dimension: 1-1/4" x 8"
Lever Knob Design: CS - Citation
Limited Warranty: 10 Years
Lock Face Size: 8" x 1-1/4"
Manufacturer Warranty: Limited 10 Year Warranty
No Of Inners: 1
Order_ Qty: 1
Rose Escutcheon Design: M - Escutcheon
Screws: Combination
Series: ML2000 Series
Strike: ANSI Straight Lip Strike
Strike Dimension: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 236L72018
Strike Type: ASA
Strike Width: 1-1/4"
Subcategory: Mortise Locksets
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing Type: UL and cUL - UL10C Positive Pressure
