CRL 27105SH0RHSC Rixson 27 Series Satin Chrome Right Hand 3/4" Offset Floor Closer PackageCRL 27105SH0RHSC Rixson Satin Chrome 27 Series Right Hand 3/4" Offset 105 Selective Hold Open Floor Mounted Closer is engineered for both exterior and interior doors, providing exceptional reliability and performance. This floor closer features a Selective Hold Open function that allows for user-friendly operation while maintaining a robust closing mechanism. Designed to support doors up to 450 lbs (204 kg) and 48 inches (1.22 m) wide, this closer is perfect for high-traffic environments. Its built-in positive dead stop prevents the door from swinging beyond a specified angle, available in stock options of 90º and 105º. The adjustable backcheck enhances safety by controlling the door's closing speed, while separate valves for closing and latching speed adjustments ensure optimal performance. With an ANSI 156.4 Grade 1 certification, the Rixson closer guarantees quality and durability, backed by a 10-year limited warranty. The satin chrome finish not only offers a sleek appearance but also contributes to its corrosion resistance. Ideal for aluminum and hollow metal doors, this closer effectively manages the demands of everyday use while meeting various compliance standards, including UL Listing. Upgrade your door control solutions with the CRL Rixson Floor Mounted Closer for unmatched functionality and style.
Rixson Satin Chrome 27 Series Right Hand 3/4" Offset 105 Selective Hold Open Floor Mounted Closer - Complete Package
- For Exterior or Interior Doors
- Selective Hold Open Feature
- 450 Lb. (204 kg) Capacity
- Built-In Positive Dead Stop
- Adjustable Backcheck
- ANSI 156.4 Grade 1
- 10 Year Limited Warranty
- UL Listed
Rixson® Floor Mounted Door Closers are a time proven product known for reliability and long-lasting service-free life. Floor Closers provide the best mechanical means of controlling a door. They produce an 85% closing force-to-opening force ratio, thereby allowing for lighter opening forces and yet maintaining control of the door. The weight of the door is supported entirely by the bottom arm, which is directly connected to the floor closer spindle. This design allows these closers to handle the rigors of high traffic volume and heavier than average doors.
Rixson® Floor Mounted Door Closers are available from CRL with multiple features and options, such as Selective Hold Open, Built-In Positive Dead Stop, Adjustable Hydraulic Backcheck. Other optional features, finishes, and accessories are available upon request.
CONTENTS:
27 Series Offset Closer Body
253000 Cement Case
274750 Finished Cover Plate
252050 Bottom Arm
R180 Top Offset Pivot
FEATURES AND SPECIFICATIONS:
Single Acting, Handed
Selective Hold Open (SHO) Stocked
Separate and Independent Valves for Closing Speed, Latching Speed, and Backcheck Adjustments
Built-in Positive Dead Stop Prevents the Door From Swinging Beyond the Opening Degree Specified. (Stock 90º and 105º)
"PH" Models Meet ANSI A117.1 Physically Handicapped 8.5 Lb. A.D.A. Opening Force
450 Lb. (204 kg), 48" (1.22 m) Width Capacity. Manufacturer Recommends Using One Intermediate Pivot for Doors up to 90" (2.29 m) Tall, and One Additional Intermediate Pivot for Each Additional 30" (762 mm)
Product Warning:
Closers set to comply with A.D.A. specified opening forces might not provide adequate spring power to control and close the door due to varying site conditions and door size.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Attributes
Adjustable Back Check: Yes
Body Height: 4-1/16 in. (103.2 mm)
Body Length: 11-1/8 in. (282.6 mm)
Body Widt: 6-1/8 in. (155.6 mm)
Body Width: 6-1/8 in. (155.6 mm)
Built In Positive Dead Stop: Yes
Certification: ANSI 156.4 Grade 1
Closer Type: Floor Closer
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Door Opening: 105 °
Door Width 3/4 Offset: 48 in. (1219.2 mm)
Finish/ Color:: Satin Chrome
Handing: Right Hand
Includes: 253000, 274750RHSC, 252050RHSC, R180SC
Interior Or Exterior Doors: Yes
Maximum Weight 3/4 Offset: 450 Pounds
Package Type: Offset
Recommended Door Type: Aluminum, Hollow Metal
Replacement Parts: 253000, 274750RHSC
Selective Hold Open: Yes
Shipping Limitations: None
Similar: J990NHOD, CRL9079SC, CRL9075SC
Special Order: Non Stocked And Accessories
UL Listed: Yes
