CRL PH28105SH0LH85 Rixson PH28 8.5 lb Left Hand Floor-Mounted Closer Body, 105 Hold OpenC.R. Laurence Rixson Model PH28 8.5 Lb. Center-Hung 105 Degree Selective Hold Open Floor Mounted Closer Body Only - Left Hand delivers exceptional door control for both exterior and interior applications. Designed to support doors weighing up to 350 lbs. (158 kg) and measuring 48" (1.22 m) wide, this closer features a robust bottom arm connection directly linked to the floor closer spindle, enhancing closing efficiency over traditional surface or overhead concealed options. Standard features include a selective on or off hold open mechanism and a built-in positive dead stop, ensuring reliable performance in high-traffic areas. The closer is equipped with adjustable independent valves for closing, latching, and backcheck adjustments, allowing for tailored operation based on specific needs. With dimensions of 4-1/16 in. (103.2 mm) in height, 11-1/8 in. (282.6 mm) in length, and 5-7/8 in. (149.2 mm) in width, this floor closer is ANSI certified and compliant with A.D.A. specified opening forces. Ideal for aluminum and hollow metal doors, the Rixson Model PH28 is a dependable choice for building professionals seeking durable and effective door control solutions. For added functionality, optional accessories are available to ensure you have everything needed for installation.
Rixson Model PH28 8.5 Lb. Center-Hung 105 Degree Selective Hold Open Floor Mounted Closer Body Only - Left Hand
- For Exterior or Interior Doors Weighing Up to 350 Lbs. (158 kg) and 48" (1.22 m) Wide
- Selective On or Off Hold Open
- Built-in Positive Dead Stop
This
Rixson® Model 28 Center-Hung Floor Mounted Door Closer provides the best mechanical means of controlling a door. The weight of the door is supported by the bottom arm, which is directly connected to the floor closer spindle. The direct connection between the bottom arm and the floor closer spindle creates a tremendous increase in closing efficiency compared to surface or overhead concealed closers. This closer is capable of supporting exterior or interior doors weighing up to 350 lbs. (158 kg) and 48" (1.22 m) Wide.
Standard features include selective on or off hold open, build-in positive dead stop, and separate independent valves for closing, latch and backcheck adjustments.
NOTE: Although A.D.A. Series Door Closers comply with A.D.A. specified opening forces, they might not provide adequate spring power to control and close the door due to varying site conditions and door size.
NOTE: CRL is a stocking Rixson® Specialty Door Control Distributor. If you need Rixson® products please contact our CRL Technical Sales Department for assistance.
Optional accessories that may be needed are:
253000
Floor Closer Cement Case
284720LH
Closer Cover
282026
Bottom Center-Hung Arm
340
Top Center-Hung Pivot
Additional finishes and accessories are available upon request for quotation.
Product Warning:
Closers set to comply with A.D.A. specified opening forces might not provide adequate spring power to control and close the door due to varying site conditions and door size.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable Hydraulic Backcheck: Yes
Americans with Disabilities Act: Yes
Body Height: 4-1/16 in. (103.2 mm)
Body Length: 11-1/8 in. (282.6 mm)
Body Widt: 5-7/8 in. (149.2 mm)
Body Width: 5-7/8 in. (149.2 mm)
Brand: Rixson
Built In Positive Dead Stop: Yes
Certification: ANSI 117.1, ANSI 156.4 Grade 1
Closer Body Only: Yes
Closer Type: Floor Closer
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Door Height: 102 in. (2590.8 mm)
Door Opening: 105 °
Handing: Left Hand
Independent Closing and Latching Valves: Yes
Interior Or Exterior Doors: Yes
Maximum Door Width - Exterior: 48 in. (1219.2 mm)
Maximum Door Width - Interior: 48 in. (1219.2 mm)
Maximum Weight Center Hung: 350 lbs. (158.8 kg)
Non Stocked Parts and Acessories Special Order: Yes
Recommended Door Type: Aluminum, Hollow Metal
Selective Hold Open: Yes
Series: 28
Shipping Limitations: None
Similar: BTS75VBF90HO, BTS80BF, J993HOD, J994HOD
Spring Size: 8.5
UL Listed: Yes
