Design Hardware KIL-IC FLAT STOREROOM 26D SFIC Storeroom Key in Lever Trim offers a robust and reliable solution for your access control needs. Designed for use with 1000R and 2000R exits, this standard-duty lever trim combines functionality with a sleek aesthetic. Its non-handed design ensures easy installation and versatility, making it suitable for various door configurations. Constructed with a durable steel and zinc die-chromated chassis, the KIL-IC lever trim features a secure through-bolted design that enhances its strength and longevity. The flat lever, made from solid zinc diecast, boasts a total projection of 2-7/8", providing a comfortable grip while meeting ADA requirements as per ANSI A117.1 standards. Installation is simplified with a door prep compatible with 2-1/8" 161 door prep specifications, and the trim accommodates standard door thicknesses of 1-3/4" and can be specified for 2" doors upon ordering. Available in a range of finishes, including satin chrome (US26D/626), this trim not only performs well but also adds an elegant touch to any entryway. With a limited lifetime warranty backing its quality, the Design Hardware KIL-IC FLAT STOREROOM lever trim is an excellent choice for professionals seeking reliability and style in security hardware.

SFIC Storeroom Key in Lever Trim for 1000R and 2000R Exits, Reversible Handing, 626/US26D Satin Chrome

Features:

• Through bolted design
• Non-Handed
• Zinc die-chromated chassis

Specifications:

• ANSI: ANSI A156.3, grade 1
• ADA: Meets ADA requirements ANSI A117.1
• Construction: Steel, zinc dichromated chassis with secure thru bolted design
• Application: Standard duty lever trim option for 1000R & 2000R (not recommended for SVR devices, heavy duty LE trim recommended)
• Door Prep: Installs in 2-1/8" 161 door prep
• Actuator: Cross shaped stainless steel
• Lever: 5" Solid zinc diecast lever - 2-7/8" total projection
• Lever Designs: Flat (standard, shown above) curved, half curved, S-A & S-B
• Rose: 3-3/8" wrought brass roses
• Handing: Non-handed completely reversible
• Door Thickness: 1-3/4" standard - available for 2" thick doors, specify when ordering
• Functions: Passage, storeroom & entry
• Cylinders Options: 6 Pin brass, C Kwy, with 2 keys std., prepared for small format IC core (less core)
• Warranty: Limited lifetime warranty

Finishes:

• US3/605 - Bright/polished brass
• US4/606 - Brushed/satin brass
• US10B/613 - Oil rubbed bronze
• US26/625 - Bright/polished chrome
• US26D/626 - Brushed/satin Chrome
• US32D/630 - Brushed/satin stainless steel
