Falcon W581CP6D D 606 Grade 2 Storeroom Lock offers a robust solution for securing lower traffic doorways in various settings, including government, retail, and multi-family environments. This Grade 2 cylindrical lock features a key-in-lever cylinder with a stylish Dane lever and a standard rose, all finished in a sleek satin brass that complements most commercial door trim. Designed for versatility, the non-handed W581CP6D accommodates door thicknesses ranging from 1-3/8" to 2". It comes standard with a 2-3/4" backset, ensuring compatibility with a wide array of applications. The lock mechanism is constructed from durable brass and cold-formed steel, further enhanced with zinc plating for rust resistance. Its self-adjusting latches and heavy wrought rose provide durability and security. The Falcon W Series locks also feature conventional cylinders and small format interchangeable cores, making them compatible with SFIC products from other manufacturers. With a 3-hour fire rating and ANSI/BHMA Grade 2 certification, this lock ensures reliability and safety. Additionally, the W581CP6D is master-keyable across the Falcon product line, offering convenience for complex access control needs. Secure your space effectively with this dependable storeroom lock from Falcon.

Grade 2 Storeroom Lock

Grade 2 Storeroom Cylindrical Lock, Key in Lever Cylinder, Dane Lever, Standard Rose, Satin Brass Finish, Non-handed

Falcon is dedicated to providing a solid product at a solid price no matter the application. When an affordable lock is needed for lower traffic doorways in government, retail, industrial or multi-family applications, the W Series lock fits perfectly. With two popular lever and knob styles as well as two popular rose diameters (big and small), Falcon can match most commercial door trim. The Falcon W Series locks feature conventional cylinders and small format interchangeable cores that are compatible with SFIC products from other manufacturers. Our conventional cylinders are available in all Falcon conventional key sections, as well as Schlage C keyway, which we now masterkey across the complete Falcon product line.

Feature conventional cylinders and small format interchangeable cores that are compatible with SFIC products from other manufacturers.

• Door Thickness: 1-3/8” to 1-3/4” standard.
• Backset: 2-3/4” standard; 2-3/8” also available.
• Mechanism: Parts constructed of brass or cold-formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
• Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose-mounting assembly, and two screws that screw into the chassis assembly.
• Handing: Locks are non-handed.
• Cylinder: Pinning in six chambers. Cylinder assemblies removable to re-key. Also available with 6- or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are stainless steel. Two nickel silver keys furnished standard.
• Competitor Cylinder: The W Series accepts standard 6-pin cylinders available from Falcon, as well as Schlage, Corbin-Russwin, Yale and Sargent.
• Keyways: “G” keyway standard on Falcon standard cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways. Schlage “C” keyway also available on standard cylinders, includes master key. Master keying available on all Falcon and Schlage “C” keyways.
• Trim: Roses are heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure-cast zinc (solid levers-no-inserts) finished to match mating parts.
• Latches: 1/2” bolt projection made of stainless steel and UL listed for 3-hour door assemblies. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2-3/8” backset with 1” x 2-1/4” latch faces or 2-3/4” backset with 1-1/8” x 2-1/4” latch faces.
• Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strikes, sizes and configurations.
• Screws: Furnished with combination screws for use in wood or metal doors and frames.
• ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 2.
• UL: 3-hour A label.

Resources

• Falcon Cylindrical Lock Guide
• T/W Series Data Sheet
• Video: Falcon W Series Small Rose Lock Installation
• Von Duprin Finishes Chart
• W Series Sell Sheet
• W Series Small Rose Installation Instructions, Dummy Trim
• W Series Small Rose Installation Instructions, Lever
• W Series W12 Lever Installation Instructions
• W Series with Levers Installation Instructions
