Folger Adam 310-2 3/4OB 629 310-2 3/4" OB Faceplate Only

Folger Adam 310-2 3/4OB 629 is a robust faceplate designed specifically for heavy-duty electric strike applications. Constructed entirely from bright stainless steel, this faceplate ensures exceptional durability and corrosion resistance, making it perfect for high-abuse environments. Rated for 3 hours of fire resistance, this device meets stringent safety standards, including UL 10C for single and double doors and is also burglary-resistant listed under UL 1034. The 310 Series features a tamper-resistant design and is engineered to withstand significant force, boasting a static strength of 1,500 lbs. and dynamic strength of 70 ft-lbs. Its endurance rating of 500,000 cycles guarantees long-lasting performance. The horizontally adjustable keeper allows for easy accommodation of door and frame misalignment, ensuring a reliable fit. With a non-handed configuration and fail secure operation, installation is straightforward, catering to various cylindrical locks, mortise exit, and latch locks. This faceplate is UL294 (6th Edition) listed and complies with NFPA-252 fire door standards, making it ideal for commercial applications. Backed by a five-year limited warranty, the Folger Adam 310-2 3/4OB 629 delivers the strength and reliability you need for secure access control solutions.

310-2 3/4OB Faceplate Only

Faceplate Only, 310-2 3/4 Open Back, Bright Stainless Steel

The 310 Series is a 3 hour fire-rated, industrial grade electric strike designed for extreme heavy duty applications. The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes.

The 310 Series is a 3 hour fire-rated, industrial grade electric strike designed for extreme heavy duty applications.

 The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes.

• UL 10C fire-rated, 3 hour single door (fail secure only)
• UL 10C fire-rated, 3 hour double door (fail secure only)
• CAN4-S104 (ULC-S104) fire door conformant
• UL1034, burglary-resistant listed
• UL 294 (6th Edition) listed
• ANSI/BHMA A156.31, Grade 1
• New York City accepted
• NFPA-252 fire door conformant
• ASTM-E152 fire door conformant
• RoHS compliant
• .51 Amps @ 12VDC continuous duty
• .25 Amps @ 24VDC continuous duty
• Tamper resistant, heavy-duty construction
• Constructed entirely of stainless steel for strength and corrosion resistance
• Static strength 1,500 lbs.
• Dynamic strength 70 ft-lbs.
• Endurance rating 500,000 cycles
• Horizontally adjustable keeper to allow for door and frame misalignment
• 1/2" keeper depth (310-2)
• Non-handed
• Fail Secure (standard)
• Plug-in connector
• Five year limited warranty
• Fail Safe
• LCBMA - Latchbolt & Locking Cam Monitor with Auxiliary Switch (all except 310-2 3/4OB)

Resources

• 310 Series Electric Strikes Cut Sheet
• AA ESH Electric Strike Overview
• Electric Strike Selector Guide
