Hafele 409.43.713 Lateral Door System, LIN-X800 offers a sophisticated solution for spaces where traditional swing doors may be impractical. With a striking black finish, this system stands at a height of 2980 mm (117 5/16") and is designed to accommodate doors weighing up to 88 lbs. The lateral swing mechanism operates with a small radius, making it an ideal choice for tight areas while ensuring efficient access. This system is non-handed and features adjustable capabilities in four directions-horizontal, vertical, depth, and parallel-allowing for precise installation tailored to your specific requirements. The built-in dampers guarantee a smooth, soft-closing movement, enhancing both functionality and user experience. While specifically designed for overlay applications, the LIN-X800 can also be installed flush with cabinets or walls, providing flexibility in design options. Constructed from durable aluminum and steel, this door system is engineered for longevity and performance. For any additional details or assistance, Hafele's customer service team is readily available to guide you through your installation process. Elevate your space with the Hafele 409.43.713, where style meets practicality in seamless door solutions.
Lateral Door System, LIN-X800
Black 2980 mm height
Designed for overlay applications, but can be installed flush with cabinet or wall. For details contact customer service.
Color/finish: Black
Door weight max.: 88 lbs
For door height: 2,980 mm
Height (inch): 117 5/16"
Material: Aluminum and steel
Side panel thickness max.: 1 9/16"
Side panel thickness min.: 15/16"
