Hafele 421.50.826 FR 777A Full Extension Cabinet Slide, Top/Bottom Mount, 440 lbs Capacity
Images may not represent actual product and finish

Hafele 421.50.826 FR 777A Full Extension Cabinet Slide, Top/Bottom Mount, 440 lbs Capacity

Your Price: $929.43
Retail Price:$1,349.93
Your Savings:$420.50(31%)
The Hafele 421.50.826 cabinet slide offers full extension, supports up to 440 lbs, and ensures quiet operation with durable materials.
Part Number : HAF_42150826
Availability: 1 In Stock
Visa, Mastercard, American Express, Discover, PayPal, Amazon Pay

Net 30 terms available

Hafele 421.50.826 FR 777A Full Extension Cabinet Slide, Top/Bottom Mount, 440 lbs Capacity

Hafele 421.50.826 Top/Bottom Mounted Cabinet Slide, FR 777A, offers an exceptional solution for pull-out cabinets with its impressive full extension capability and a weight capacity of 440 lbs. The installed length of 700 mm (27 9/16") ensures compatibility with a variety of cabinet sizes, making it a versatile choice for both residential and commercial applications. Designed with high-quality steel ball bearings, this cabinet slide guarantees smooth operation and quiet performance, enhanced by its integrated differential action. The U-profile, which is closed on one end, serves as an effective end stop for the guide roller, providing additional stability. The all-plastic stops are a thoughtful feature that minimizes any potential rubbing noises during operation. Installation is straightforward, with options for both top and bottom mounting, while the slide's epoxy-coated white finish adds a clean, modern look to your cabinetry. With a maximum height allowance of 98 inches, this slide accommodates a wide range of cabinet designs. Supplied with both top and bottom slides along with clear instructions, the Hafele 421.50.826 is an ideal choice for professionals seeking reliable, high-performance cabinet fittings.

Top/Bottom Mounted Cabinet Slide, FR 777A, Full Extension, 440 lbs Weight Capacity

(27 9/16") 700 mm installed length


Good running characteristics and quietness due to integrated differential action All stops are made of plastic Patented profile shapes prevent rubbing noises Easy running due to high quality steel ball bearings Rear stop Ceiling guide for lateral stability U-profile is closed on one end to function as an end stop for the guide roller

The running tracks of these guides should not be lubricated.


Attributes

Area of application: Pull-out cabinets

Color/finish: White, Epoxy-coated

Extension length: 684.00 mm

Height (inch): Max: 98"

Installation: Tip/bottom mounted Floor mounted

Installation length: 700.00 mm

Load bearing capacity: 200.00 kg

Material: Guides: Steel Rollers: Solid Delrin, Steel ball bearing (encased)

Supplied with: Bottom slide Top slide Instructions

Version: Full extension progressive runner
