Hafele 833.75.376 Hafele Slim6 Flexible Silicone LED 3084 24V, Medium IntensityHafele 833.75.376 Flexible Slim6 Silicone is a versatile LED strip light designed for seamless integration into display cabinets and storage spaces. This medium intensity lighting solution features a monochrome COB design, measuring 6.5 x 6 mm, and delivers an impressive 680 lumens per meter with a warm white color temperature of 3000K. With a strip length of 5 meters (196 7/8"), it can be easily customized to fit various applications, as it can be shortened every 50 mm (2"). The flexible silicone construction allows for curved installations with a minimum bending radius of 15 mm (19/32"), ensuring that LED dots remain invisible for a polished look. The strip is rated IP44, providing protection against dust and splashes, making it suitable for diverse environments. Installation is straightforward, requiring no additional profiles or leads, and is designed for recessed mounting with a routing depth of 6 mm and width of 6.5 mm. This product comes in two configurations: a 0.85 m roll with a 1 m lead cable soldered on one end, and a 3 m roll with two 1 m lead cables. With a maximum visual strip length of 3.5 m, it maintains a consistent luminous output, ensuring your spaces are beautifully illuminated.
Flexible Slim6 Silicone, Hafele Lighting LED 3084 24 V, Medium Intensity
COB 6.5 x 6 mm, 2-pin (monochrome), 320 LEDs/m, 9.6 W/m, IP44, Warm white 3000K, strip light length 5 m (196 7/8"), lead 2 x 1 m (39 3/8")
For recessed installation in a 6.5 mm (1/4") wide x 6 mm (15/64") deep channel Mounts flush with panel Flexible silicone allows for curved applications (radius min. 15 mm (19/32") LED dots are not visible
Cut marks visible on back of ribbon: - Can be shortened every 50mm (2") - 0.85 m (33 25/32") roll is supplied with a 1 m (39 3/8") lead cable soldered on one end - 3 m (118 7/64") roll is supplied with a 1 m (39 3/8") lead cable soldered on each end. The strip can be divided into two sections.
Ready to install. No additional profiles or leads required. Use 1/4" router bit
Maximum strip length (visual) 3.5 m (138") describes a strip section with a visually imperceptible drop in luminous flux of max. 30%. Please note: A directly following strip section with a new infeed is noticeably lighter. Maximum wattage-dependent strip length on the driver, see Technical data for LED strip lights.
Attributes
Area of application: Display cabinets, Storage spaces
Cable length: 1,000.00 mm
Color: White
Color temperature: 3,000 K
Contact surface length: 6.00 mm
Degree of protection: IP44
Dimmable: yes
Installation: For recess mounting, For press fitting
Installation reference: After cutting the silicone tube, a seal is required to restore the degree of protection IP44.
Light color: Warm white
Luminous efficacy: >71 lm/W
Luminous flux per Meter: 680 lm
Material: Silicone
Max. strip length (visual): 3.50 m
Min. bending radius: 15.00 mm
Routing depth: 6.00 mm
Routing width: 6.50 mm
Section length: 50.00 mm
Silicone hose height: 6.00 mm
Silicone tube finish: matte
Silicone tube width: 6.50 mm
Supplied with: 0.85 m (33 25/32") roll; 1 LED strip with one attached 1 m (39 3/8") lead 3 m (118 7/64") roll; 1 LED strip with two attached 1 m (39 3/8") leads
Wattage/m: 9.60 W
