Hafele 833.76.516 Hafele Loox5 3104 COB Gold LED Strip Light, 24VHafele 833.76.516 LED strip light, COB Gold, Hafele Loox5 LED 3104 24 V offers an exceptional lighting solution tailored for indirect illumination. With a sleek profile measuring just 8 mm in width, this self-adhesive strip light seamlessly integrates into various designs, perfect for furniture, storage spaces, and behind glass edges. The warm white light at 3000 K provides a cozy ambiance, while the COB (Chip on Board) technology ensures a uniform light output without visible LED dots, enhancing visual appeal. This strip features a luminous efficacy of 93 lm/W and a luminous flux of 900 lm per meter, delivering brilliant illumination with energy efficiency class F. The maximum visual strip length reaches up to 5.00 m, providing flexibility in design without a noticeable drop in luminous flux. Dimmable capabilities allow for customizable lighting levels, catering to different moods and settings. Rated IP20, this LED strip is suitable for indoor applications. Its robust construction and minimal bending radius of 30 mm make it easy to install in various environments. The Hafele 833.76.516 is supplied in a 50-meter roll, ensuring you have enough length for extensive projects while maintaining exceptional performance throughout.
LED strip light, COB Gold, Hafele Lighting LED 3104 24 V
8 mm 2-pin (monochrome), 480 LEDs/m, 9.6 W/m, IP20, warm white 3000 K, 50 m
Uniform light output; LED dots are not visible Enables the use of shallow profiles
Maximum strip length (visual) describes a strip section with a visually imperceptible drop in luminous flux of max. 30%. Please note: A directly following strip section with a new infeed is noticeably lighter. Maximum wattage-dependent strip length on the driver, see Technical data for LED strip lights.
Attributes
Area of application: Indirect illumination of furniture and furnishings, Storage spaces, Behind glass edges
Color temperature: 3,000 K
Contact surface length: 50,000.00 mm
Degree of protection: IP20
Dimmable: yes
Energy efficiency class: F
Height (inch): 1/16"
Installation: Self-adhesive
Light color: Warm white
Luminous efficacy: 93 lm/W
Luminous flux/m: 900 lm
Max. strip length (visual): 5.00 m
Min. bending radius: 30.00 mm
Nominal voltage: 24.00 V
Order reference: Please order lead separately. Aluminum profile is recommended from 9.6 W/ m.
Section length: 16.67 mm
Strip height: 2.00 mm
Strip length: 50.00 m
Strip width: 8.00 mm
Supplied with: 1 roll
Version: COB LED, i.e. continuous phosphor coating over all individual LEDs of the entire band, without visible points
Wattage/m: 9.60 W
Width (inch): 5/16"
