Hafele 833.76.520 Hafele Loox5 3105 COB Gold LED Strip Light, 24VHafele 833.76.520 LED strip light, COB Gold, Hafele Loox5 LED 3105 24 V offers a sleek and efficient lighting solution for a variety of applications. Designed with a warm white color temperature of 2700 K, this strip light measures 5 meters in length and features a uniform light output with 480 LEDs per meter, ensuring no visible LED dots for a seamless illumination experience. Operating at 14.4 W per meter, this energy-efficient strip boasts a luminous efficacy of 85 lm/W, delivering a luminous flux of 1,235 lumens per meter. Its IP20 rating makes it ideal for indirect lighting in furniture, storage spaces, or behind glass edges, while its self-adhesive installation simplifies setup. With a maximum visual strip length of 4 meters before any drop in luminous flux becomes perceptible, this LED strip can be easily customized to fit your lighting needs. The minimum bending radius of 30 mm allows for versatile placement in tight spaces. Additionally, it is dimmable, providing flexibility in light intensity. For optimal performance, it is recommended to pair this strip with an aluminum profile when exceeding 9.6 W/m. Enhance your space with the Hafele 833.76.520 LED strip light and enjoy the perfect blend of functionality and style.
LED strip light, COB Gold, Hafele Lighting LED 3105 24 V
8 mm 2-pin (monochrome), 480 LEDs/m, 14.4 W/m, IP20, warm white 2700 K, 5 m
Uniform light output; LED dots are not visible Enables the use of shallow profiles
Maximum strip length (visual) describes a strip section with a visually imperceptible drop in luminous flux of max. 30%. Please note: A directly following strip section with a new infeed is noticeably lighter. Maximum wattage-dependent strip length on the driver, see Technical data for LED strip lights.
Attributes
Area of application: Indirect illumination of furniture and furnishings, Storage spaces, Behind glass edges
Color temperature: 2,700 K
Contact surface length: 5,000.00 mm
Degree of protection: IP20
Dimmable: yes
Energy efficiency class: G
Height (inch): 1/16"
Installation: Self-adhesive
Light color: Warm white
Luminous efficacy: 85 lm/W
Luminous flux/m: 1,235 lm
Max. strip length (visual): 4.00 m
Min. bending radius: 30.00 mm
Nominal voltage: 24.00 V
Order reference: Please order lead separately. Aluminum profile is recommended from 9.6 W/ m.
Section length: 16.67 mm
Strip height: 2.00 mm
Strip length: 5.00 m
Strip width: 8.00 mm
Supplied with: 1 roll
Version: COB LED, i.e. continuous phosphor coating over all individual LEDs of the entire band, without visible points
Wattage/m: 14.40 W
Width (inch): 5/16"
