Hafele 903.00.074 Pull Handle, StarTec Stainless Steel is a striking addition to any entrance, designed to enhance both functionality and aesthetics. With a 23 5/8" center-to-center (CTC) distance, this pull handle is perfectly suited for glass, wood, and aluminum doors, making it a versatile choice for various applications. The satin-finish stainless steel construction, crafted from high-quality AISI 304, ensures durability and a sleek appearance that complements modern interiors. This handle is specifically designed for back-to-back mounting, supplied with all necessary hardware for seamless installation. It accommodates a range of door thicknesses-5/16" to 9/16" for glass and 1 5/16" to 1 15/16" for wood-making it adaptable to different environments. The suitable glass thickness ranges from 8 to 15 mm, and the wood thickness can vary from 34 to 50 mm, providing flexibility for builders and homeowners alike. With a drill hole diameter of 13.00 mm and hole spacing of 600.00 mm, the Hafele StarTec Pull Handle is easy to install and ensures a secure fit. Enhance your project with this elegant and functional hardware solution that promises both style and reliability.
Pull Handle, StarTec Stainless Steel
23 5/8" CTC
Area of application: For glass or wooden doors For back to back application
Color/finish: satin-finish
Dim. C: 23 5/8"
Door type: Wooden doors, Aluminum doors, Glass doors
Drill hole Ø: 13.00 mm
For door thickness max.: 9/16" for glass; 1 15/16" for wood
For door thickness min.: 5/16" for glass; 1 5/16" for wood
For glass thickness: 8 – 15 mm
For wood thickness: 34 – 50 mm
Hole spacing: 600.00 mm
Length: 630.00 mm
Material: Stainless steel, quality 1.4301/AISI 304
Supplied with: Back-to-back mounting hardware
