Hafele 927.91.540 Door Hinge, Startec H2 offers a robust solution for flush interior wooden doors with its innovative 3D adjustable design. Measuring 95 mm in size and crafted from high-quality zinc alloy with a sleek matt nickel plating, this hinge combines durability with modern aesthetics. It allows for precise adjustments in three dimensions, ensuring optimal alignment and functionality. The hinge supports a maximum door weight of 110 lbs with two hinges or up to 132 lbs with three, accommodating a wide range of applications. Designed for door heights up to 2,000 mm, it requires four hinges for doors exceeding 2,100 mm. With an impressive opening angle of 180 degrees, the Startec H2 hinge facilitates easy access and smooth operation. The flange features a rounded shape with dimensions of 23.3 mm in width, enhancing its visual appeal while ensuring a secure fit in wooden frames. Certified in compliance with EN 1935:2002, this hinge promises reliability and safety. Installation is made simple with included fixing materials and a hex key for adjustments. Whether for residential or commercial projects, Hafele’s 927.91.540 Door Hinge provides the perfect blend of functionality and style, making it an ideal choice for discerning builders and homeowners alike.
Door Hinge, Startec H2
3D adjustable, size 95 mm, Zinc alloy, satin nickel
Different recess dimensions when using hinge pockets for lining frames. 4 door hinges must be used for door height of 2,100 mm and above.
Adjustment facility: 3DContinuous, Side: 3 mm, Height: -2.5 – 2.5 mm, Closing pressure: ±1 mm
Area of application: For flush interior wood doors - 3D Adjustable
Color/finish: satin-finish, nickel plated
Door height max.: 2,000.00 mm
Door height min.: 82 11/16" with 4 hinges
Door thickness: ≥32 mm
Door weight max.: 110 lbs with 2 door hinges; ≤ 132 lbs with 3 door hinges
Door width max.: 900.00 mm
Flange height: 95 mm
Flange shape: rounded
Flange width: 23.3 mm
For door thickness min.: 1 1/4"
For door type: Wooden door leaf
For door width (inches): ≤ 35 7/16"
For frame type: Wooden frame
Grade: 2|7|2|1|1|4|0|7
Material: Zinc alloy
Max. door weight for 2 hinges: 45.00 kg
Max. door weight for 3 hinges: 60.00 kg
Model: H2
Opening angle: 180.00 °
Order reference: Hex key for adjustment supplied. Fixing material supplied.
Standard: Certified in compliance with EN 1935:2002
