Hafele 940.64.017 Hollow Stainless Steel Track Set offers a robust solution for sliding wood doors, featuring a polished stainless steel finish that enhances both durability and aesthetics. With a length of 1.8 meters (5’ 10 7/8"), this track set is designed for doors weighing up to 100 kg (220 lbs) and widths not exceeding 900 mm. Its maintenance-free operation ensures smooth and quiet functionality, making it ideal for both residential and commercial applications. Installation is straightforward, with wall mounting as the primary option, and an adjustment facility allowing for height modifications between -3 mm to +3 mm (±1/8"). The set is supplied with essential components, including 4-5 wall attachments, 2 door stoppers, and 2 running gears, along with a hex key and detailed installation plan. However, please note that hangar bolts, compensation disks, and spacers are not included and need to be ordered separately. Designed specifically for wood doors with thicknesses ranging from 35 to 45 mm (1 3/8" to 1 3/4"), the Hafele Hollow Stainless Steel Track Set is a reliable choice for any sliding door solution, ensuring both functionality and style.
Hollow Stainless Steel Track Set
Flatec IV for Wood Doors, 1.8 m length, polished
Adjustment facility: Height adjustment facility: -3 – 3 mm, Height: (±1/8") ±3 mm
Area of application: For 1 sliding wood door
Controller installation options: Wall mounting
For door material: wood
For door thickness: 35 – 45 mm
For door thickness max.: 1 3/4"
For door thickness min.: 1 3/8"
For door weight: ≤100 kg
For door width: ≤900 mm
Length (inch): 5’ 10 7/8"
Load bearing capacity: 220 lbs.
Material/finish: Stainless steel
Number of doors: 1.00
Order reference: Hangar Bolts, Compensation Disks and Spacers are not included and need to be ordered separately.
Running position: Top
Running track length: 1,800.00 mm
Supplied with: 4-5 wall attachments 2 door stoppers 2 running gears Upper track Lower guide Hex key Installation plan included in fitting set, also available for planning and execution upon request
